Yamaha YZ250F 2020 specifications pictures and more for the 2020 Yamaha YZ250F in South Africa brought to you by Motomedia

Yamaha YZ250F 2020 motorcycle info

Main Detail

Make

Yamaha

Model

YZ250F

Year

2020

Dimensions and Weight

Ground Clearance

335 mm / 13.2 inches

Overall Height

1285 mm / 50.6 inches

Overall Length

2174 mm / 85.6 inches

Overall Width

826 mm / 32.5 inches

Kerb Weight

106.1 kg / 234.0 pounds

Wheelbase

1476 mm / 58.1 inches

Engine and Exhaust

Bore / Stroke

77.0 x 53.6 mm / 3.0 x 2.1 inches

Engine Capacity

250.0 cc / 15.26 cubic inches

Compression

13.8:1

Engine Detail

Titanium-valves

Engine Type

Single cylinder, four-stroke

Ignition

TCI: Transistor Controlled Ignition

Starter

Kick

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain (final drive)

Gearbox

5-speed

Clutch

Multiplate wet clutch

Lubrication System

Wet sump

Oil Capacity

0.90 litres / 0.95 US quarts

Fuel and Emission Standards

Fuel System

Injection. Mikuni fuel injection, 44mm

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Capacity

6.06 litres / 1.60 US gallons

Suspension

Front Suspension

KYB speed-Sensitive System, inverted fork: fully adjustable

Front Wheel Travel

310 mm / 12.2 inches

Rear Suspension

KYB fully adjustable single shock

Rear Wheel Travel

318 mm / 12.5 inches

Tires and Rims

Front Tire

80/100-21

Rims

Bridgestone® M403A tyres

Brakes

Front Brakes

Single disc. Hydraulic.

Rear Brakes

Single disc. Hydraulic.

Notes, Comments and Warranty Information

Factory Warranty

30 Day Limited Factory Warranty

Colour Options

Team Yamaha Blue, Gray

Yamaha YZ250F 2020 specs
