Yamaha YZ125X 2023 specifications pictures and more for the 2023 Yamaha YZ125X in South Africa brought to you by Motomedia

Yamaha YZ125X 2023 specs

Latest motor bike specifications and pictures for the 2023 Yamaha YZ125X.



Yamaha YZ125X 2023 motorcycle info

Main Detail

Make
Yamaha
Model
YZ125X
Year
2023
Category
Enduro / Off-Road

Dimensions and Weight

Ground Clearance
351 mm / 13.8 inches
Overall Height
1285 mm / 50.6 inches
Overall Length
2141 mm / 84.3 inches
Overall Width
825 mm / 32.5 inches
Trail
117 mm / 4.6 inches
Kerb Weight
96.2 kg / 212.0 pounds
Wheelbase
1455 mm / 57.3 inches

Engine and Exhaust

Bore / Stroke
54.0 x 54.5 mm / 2.1 x 2.1 inches
Engine Capacity
125.0 cc / 7.63 cubic inches
Compression
10.2:1
Engine Detail
Reed-valve-inducted
Engine Type
Single cylinder, two-stroke
Ignition
CDI
Starter
Kick

Transmission (Gearbox) and Final Drive

Transmission Type
Chain   (final drive)
Gearbox
6-speed
Clutch
O-ring chain
Lubrication System
Premix
Oil Capacity
0.70 litres / 0.74 US quarts

Fuel and Emission Standards

Fuel System
Carburettor. Hitachi Astemo® Keihin PWK38S
Fuel Capacity
6.81 litres / 1.80 US gallons

Suspension

Front Suspension
KYB® Speed-Sensitive System inverted fork; fully adjustable
Front Wheel Travel
300 mm / 11.8 inches
Rear Suspension
KYB® single shock; fully adjustable
Rear Wheel Travel
315 mm / 12.4 inches

Tires and Rims

Front Tire
90/90-21
Rims
Dunlop® Geomax MX33 tires

Brakes

Front Brakes
Single disc. Hydraulic.
Rear Brakes
Single disc. Hydraulic.

Notes, Comments and Warranty Information

Factory Warranty
30 Day Limited Factory Warranty
Colour Options
Team Yamaha Blue
