Yamaha TW200 2010 specifications pictures and more for the 2010 Yamaha TW200 in South Africa brought to you by Motomedia

Yamaha TW200 2010 motorcycle info

Main Detail

Make

Yamaha

Model

TW200

Year

2010

Dimensions and Weight

Ground Clearance

264 mm / 10.4 inches

Overall Height

1,120 mm / 44.1 inches

Overall Length

2,090 mm / 82.3 inches

Overall Width

820 mm / 32.3 inches

Kerb Weight

126.6 kg / 279.0 pounds

Wheelbase

1,326 mm / 52.2 inches

Engine and Exhaust

Bore / Stroke

67.0 x 55.7 mm / 2.6 x 2.2 inches

Engine Capacity

196.00 cc / 11.96 cubic inches

Compression

9.5:1

Engine Type

Single cylinder, four-stroke

Ignition

CDI

Starter

Electric

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

5-speed

Clutch

Multiple-disc wet clutch

Fuel and Emission Standards

Fuel System

Carburettor. Mikuni® 28mm

Fuel Control

SOHC

Fuel Consumption

3.01 litres/100 km (33.2 km/l or 78.15 mpg)

Fuel Capacity

6.81 litres / 1.80 gallons

Greenhouse Gases

69.8 CO

Suspension

Front Suspension

Telescopic fork

Front Suspension Travel

160 mm / 6.3 inches

Front Wheel Travel

160 mm / 6.3 inches

Rear Suspension

Single shock

Rear Wheel Travel

150 mm / 5.9 inches

Tires and Rims

Front Tire Dimensions

130/80-18

Rear Tire Dimensions

180/80-14

Brakes

Front Brakes

Single disc

Front Brake Diameter

220 mm / 8.7 inches

Rear Brakes

Expanding brake (drum brake)

Rear Brake Diameter

110 mm / 4.3 inches

Notes, Comments and Warranty Information

Colour Options

White/Red
