Yamaha PW50 2022 specifications pictures and more for the 2022 Yamaha PW50 in South Africa brought to you by Motomedia

Yamaha PW50 2022 specs

Latest motor bike specifications and pictures for the 2022 Yamaha PW50.



Yamaha PW50 2022 motorcycle info

Main Detail

Make
Yamaha
Model
PW50
Year
2022
Category
Minibike, cross

Dimensions and Weight

Ground Clearance
94 mm / 3.7 inches
Overall Height
706 mm / 27.8 inches
Overall Length
1245 mm / 49.0 inches
Overall Width
610 mm / 24.0 inches
Trail
50 mm / 2.0 inches
Kerb Weight
41.0 kg / 90.4 pounds
Wheelbase
856 mm / 33.7 inches

Engine and Exhaust

Bore / Stroke
40.0 x 39.2 mm / 1.6 x 1.5 inches
Engine Capacity
49.0 cc / 2.99 cubic inches
Compression
6.0:1
Engine Detail
Reed-valve
Engine Type
Single cylinder, two-stroke
Ignition
CDI
Starter
Kick

Transmission (Gearbox) and Final Drive

Transmission Type
Shaft drive (cardan)   (final drive)
Gearbox
Automatic
Clutch
Wet centrifugal automatic clutch
Lubrication System
Separate 2-stroke oil tank

Fuel and Emission Standards

Fuel System
Carburettor. Mikuni VM12
Fuel Capacity
2.01 litres / 0.53 US gallons

Suspension

Front Suspension
Telescopic fork 26mm
Front Wheel Travel
61 mm / 2.4 inches
Rear Suspension
Unit swingarm
Rear Wheel Travel
51 mm / 2.0 inches

Tires and Rims

Front Tire
2.50-10
Rims
3-spoke

Brakes

Front Brakes
Expanding brake (drum brake)
Rear Brakes
Expanding brake (drum brake)

Notes, Comments and Warranty Information

Comments
Intended for children. Easy-to-adjust throttle limiter.
Factory Warranty
90 Day Limited Factory Warranty
Colour Options
Team Yamaha Blue
