Yamaha MT-09 2015 motorcycle info

Main Detail

Make

Yamaha

Model

MT-09

Year

2015

Performance and Speed

Torque

87.50 Nm (8.9 kgf-m or 64.5 ft.lbs) @ 8900 Revolutions">RPM

Dimensions and Weight

Ground Clearance

135 mm / 5.3 inches

Overall Height

1,135 mm / 44.7 inches

Overall Length

2,075 mm / 81.7 inches

Overall Width

815 mm / 32.1 inches

Trail

103 mm / 4.1 inches

Kerb Weight

188.0 kg / 414.5 pounds

Wheelbase

1,440 mm / 56.7 inches

Engine and Exhaust

Bore / Stroke

78.0 x 59.1 mm / 3.1 x 2.3 inches

Engine Capacity

847.00 cc / 51.68 cubic inches

Compression

11.5:1

Engine Type

In-line three, four-stroke

Ignition

TCI

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Wet, Multiple Disc

Lubrication System

Wet sump

Oil Capacity

3.40 litres / 0.22 quarts

Fuel and Emission Standards

Fuel System

Injection

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Capacity

14.00 litres / 3.70 gallons

Suspension

Front Suspension

Telescopic forks

Front Wheel Travel

137 mm / 5.4 inches

Rear Suspension

Swingarm, (Link type suspension)

Rear Wheel Travel

130 mm / 5.1 inches

Tires and Rims

Front Tire

120/70-ZR17

Rear Tire

180/55-ZR17

Brakes

Front Brakes

Double disc. Hydraulic.

Front Brake Diameter

298 mm / 11.7 inches

Rear Brakes

Single disc. Hydraulic.

Rear Brake Diameter

245 mm / 9.6 inches

Notes, Comments and Warranty Information

Colour Options

Red, grey, blue, black
