Triumph Tiger 1200 Rally Pro 2023 specifications pictures and more for the 2023 Triumph Tiger 1200 Rally Pro in South Africa brought to you by Motomedia

Triumph Tiger 1200 Rally Pro 2023 motorcycle info

Main Detail

Make

Triumph

Model

Tiger 1200 Rally Pro

Year

2023

Performance and Speed

Power to Weight Ratio

0.6025 HP/kg

Torque

130.0 Nm (13.3 kgf-m or 95.9 ft.lbs) @ 7000 Revolutions">RPM

Dimensions and Weight

Dry Weight

249.0 kg / 548.9 pounds

Overall Height

1547 mm / 60.9 inches

Overall Width

849 mm / 33.4 inches

Trail

112 mm / 4.4 inches

Wheelbase

1560 mm / 61.4 inches

Engine and Exhaust

Bore / Stroke

89.9 x 60.5 mm / 3.5 x 2.4 inches

Engine Capacity

1160.0 cc / 70.78 cubic inches

Compression

13.2:1

Engine Type

In-line three, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Stainless steel 3 into 1 header system with underslung primary silencer and side mounted secondary silencer

Transmission (Gearbox) and Final Drive

Transmission Type

Shaft drive (cardan) (final drive)

Gearbox

6-speed

Clutch

Hydraulic, Wet, multi-plate, slip and assist

Oil Capacity

4.00 litres / 4.23 US quarts

Fuel and Emission Standards

Fuel System

Injection. Multipoint sequential electronic fuel injection with electronic throttle control

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Consumption

4.90 litres/100 km (20.4 km/l or 48.00 mpg)

Fuel Capacity

20.00 litres / 5.28 US gallons

Greenhouse Gases

113.7 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

Showa 49mm, semi-active damping USD forks

Front Wheel Travel

220 mm / 8.7 inches

Rear Suspension

Showa semi-active damping monoshock, with automatic electronic preload adjustment.

Rear Wheel Travel

220 mm / 8.7 inches

Tires and Rims

Front Tire

90/90-21

Rims

Wire spoke, aluminum rims, Metzeler Karoo Street tires

Brakes

Front Brakes

Double disc. Brembo M4.30 Stylema monoblock radial calipers, OC-ABS

Rear Brakes

Single disc. Brembo single piston caliper, OC-ABS

Instrumentation and Lighting

Instruments

TFT multifunctional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gage, service indicator, ambient temperature, clock and six rider modes

Lighting

All LED lighting

Notes, Comments and Warranty Information

Comments

Ride by wire. Traction control. Windscreen. Heated grips.

Factory Warranty

3 years unlimited mileage

Colour Options

Snowdonia White, Sapphire Black, Matte Khaki Green

Triumph Tiger 1200 Rally Pro 2023 specs
