Moto Guzzi V7 Racer 2013 motorcycle info

Main Detail

Make

Moto Guzzi

Model

V7 Racer

Year

2013

Performance and Speed

Power to Weight Ratio

0.2769 HP/kg

Top Speed

70.0 km/h / 43.5 mph

Torque

57.90 Nm (5.9 kgf-m or 42.7 ft.lbs) @ 5000

Dimensions and Weight

Dry Weight

179.2 kg / 395.0 pounds

Overall Height

1,113 mm / 43.8 inches

Overall Length

2,184 mm / 86.0 inches

Overall Width

800 mm / 31.5 inches

Wheelbase

1,490 mm / 58.7 inches

Engine and Exhaust

Bore / Stroke

87.5 x 82.0 mm / 3.4 x 3.2 inches

Engine Capacity

744.00 cc / 45.40 cubic inches

Compression

10.2:1

Engine Detail

90° V-twin

Engine Type

V2, four-stroke

Ignition

ECU

Starter

Electric

Exhaust system

Three-way catalytic converter with double lambda probe

Transmission (Gearbox) and Final Drive

Transmission Type

Shaft drive (cardan)

Gearbox

5-speed

Clutch

Dry single plate with flexible couplings

Drive line

CA.R.C. Compact Reactive Shaft Drive

Lubrication System

Forced circulation with lobe pump - circuit capacity: 1.78 Kg

Fuel and Emission Standards

Fuel System

Injection. Weber-Marelli electronic fuel injection.

Fuel Capacity

21.95 litres / 5.80 gallons

Reserve Fuel Capacity

3.79 litres / 1.00 gallons

Suspension

Front Suspension

Telescopic hydraulic fork with 40 mm stanchions

Rear Suspension

Die cast light alloy swing arm with 2 spring preload adjustable shock absorbers

Tires and Rims

Front Tire

185/88-12

Front Tire Dimensions

100/90-18

Rear Tire

270/60-12

Rear Tire Dimensions

130/80-17

Rims

Spoked polished aluminium rims

Brakes

Front Brakes

Single disc. Brembo caliper with 4 differentiated pistons

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc. Floating disc. Two-piston calipers.

Rear Brake Diameter

260 mm / 10.2 inches

Notes, Comments and Warranty Information

Factory Warranty

Two-year manufacturer?s warranty and roadside assistance for one year

Colour Options

Gray
