KTM 690 Enduro R 2019 specifications pictures and more for the 2019 KTM 690 Enduro R in South Africa brought to you by Motomedia

KTM 690 Enduro R 2019 motorcycle info

Main Detail

Make

KTM

Model

690 Enduro R

Year

2019

Performance and Speed

Power to Weight Ratio

0.4589 HP/kg

Dimensions and Weight

Dry Weight

146.0 kg / 321.9 pounds

Ground Clearance

270 mm / 10.6 inches

Wheelbase

1504 mm / 59.2 inches

Engine and Exhaust

Bore / Stroke

105.0 x 80.0 mm / 4.1 x 3.1 inches

Engine Capacity

690.0 cc / 42.10 cubic inches

Engine Detail

Balancer shaft

Engine Type

Single cylinder, four-stroke

Ignition

Keihin EMS with RBW, twin ignition

Starter

Electric

Transmission (Gearbox) and Final Drive

Transmission Type

Chain (final drive)

Gearbox

6-speed

Clutch

APTC slipper clutch, hydraulically actuated

Drive line

5/8 x 1/4 X Ring

Lubrication System

Pressure circulation lubrication with two rotor pumps

Fuel and Emission Standards

Fuel System

Injection

Fuel Capacity

13.50 litres / 3.57 US gallons

Suspension

Front Suspension

WP USD Ø 48 mm

Front Wheel Travel

250 mm / 9.8 inches

Rear Suspension

WP shock absorber with Pro-Lever linkage

Rear Wheel Travel

250 mm / 9.8 inches

Tires and Rims

Rims

Wire spoked

Brakes

Front Brakes

Single disc. Brembo twin-piston floating calliper. Optional ABS.

Rear Brakes

Single disc. Brembo single-piston floating calliper. Optional ABS.

Notes, Comments and Warranty Information

Comments

Cable-free ´ride-by-wire´ system.

Colour Options

Orange/black/white

KTM 690 Enduro R 2019 specs
