KTM 690 Enduro 2011 specifications pictures and more for the 2011 KTM 690 Enduro in South Africa brought to you by Motomedia

KTM 690 Enduro 2011 motorcycle info

Main Detail

Make

KTM

Model

690 Enduro

Year

2011

Performance and Speed

Power to Weight Ratio

0.4483 HP/kg

Torque

64.00 Nm (6.5 kgf-m or 47.2 ft.lbs) @ 6000

Dimensions and Weight

Dry Weight

138.5 kg / 305.3 pounds

Ground Clearance

300 mm / 11.8 inches

Trail

115 mm / 4.5 inches

Wheelbase

1,498 mm / 59.0 inches

Engine and Exhaust

Bore / Stroke

102.0 x 80.0 mm / 4.0 x 3.1 inches

Engine Capacity

654.00 cc / 39.91 cubic inches

Compression

11.8:1

Engine Type

Single cylinder, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Stainless steel silencer with regulated catalytic converter

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

APTC slipper clutch, hydraulically operated

Drive line

15:45. Primary drive: 36:79.

Lubrication System

Pressure lubrication with 2 Eaton pumps

Fuel and Emission Standards

Fuel System

Carburettor. Keihin FCR MX 39

Fuel Control

OHC

Fuel Capacity

12.00 litres / 3.17 gallons

Suspension

Front Suspension

WP USD 48 mm (1.89 in)

Front Suspension Travel

250 mm / 9.8 inches

Front Wheel Travel

275 mm / 10.8 inches

Rear Suspension

WP mono shock with Pro Lever Linkage

Rear Wheel Travel

272 mm / 10.7 inches

Tires and Rims

Front Tire

21/7-10

Front Tire Dimensions

90/90-21

Rear Tire

20/11-9

Rear Tire Dimensions

140/80-18

Rims

Spoked wheels with aluminium rims 1.85 x 21´´ / 2.50 x 18´´

Brakes

Front Brakes

Single disc

Front Brake Diameter

300 mm / 11.8 inches

Rear Brakes

Single disc

Rear Brake Diameter

240 mm / 9.4 inches

Notes, Comments and Warranty Information

Colour Options

Orange/black

KTM 690 Enduro 2011 specs
