KTM 690 Duke 2017 specifications pictures and more for the 2017 KTM 690 Duke in South Africa brought to you by Motomedia

KTM 690 Duke 2017 motorcycle info

Main Detail

Make

KTM

Model

690 Duke

Year

2017

Performance and Speed

Power to Weight Ratio

0.4916 HP/kg

Torque

74.00 Nm (7.5 kgf-m or 54.6 ft.lbs)

Dimensions and Weight

Dry Weight

148.5 kg / 327.4 pounds

Ground Clearance

192 mm / 7.6 inches

Wheelbase

1,466 mm / 57.7 inches

Engine and Exhaust

Bore / Stroke

105.0 x 80.0 mm / 4.1 x 3.1 inches

Engine Capacity

690.00 cc / 42.10 cubic inches

Engine Type

Single cylinder, four-stroke

Ignition

Keihin EMS with RBW, twin ignition

Starter

Electric

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

APTC slipper clutch, hydraulically actuated

Drive line

5/8 x 1/4 X Ring. Primary drive: 36:79.

Lubrication System

Semi-dry-sump lubrication with 2 rotor pumps

Fuel and Emission Standards

Fuel System

Injection

Fuel Capacity

14.00 litres / 3.70 gallons

Suspension

Front Suspension

WP upside-down ? 43 mm

Front Wheel Travel

135 mm / 5.3 inches

Rear Suspension

WP shock absorber with Pro-Lever linkage

Rear Wheel Travel

135 mm / 5.3 inches

Brakes

Front Brakes

Single disc. ABS. Floating disc. Four-piston calipers. Radially mounted.

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc. ABS. Floating disc. Single-piston caliper.

Rear Brake Diameter

240 mm / 9.4 inches

Notes, Comments and Warranty Information

Colour Options

Orange, white

KTM 690 Duke 2017 specs
