KTM 500 EXC-F 2018 specifications pictures and more for the 2018 KTM 500 EXC-F in South Africa brought to you by Motomedia

KTM 500 EXC-F 2018 specs

Latest motor bike specifications and pictures for the 2018 KTM 500 EXC-F.



KTM 500 EXC-F 2018 motorcycle info

Main Detail

Make
KTM
Model
500 EXC-F
Year
2018
Category
Enduro / Off-Road

Dimensions and Weight

Dry Weight
106.5 kg / 234.8 pounds
Ground Clearance
355 mm / 14.0 inches
Wheelbase
1,482 mm / 58.3 inches

Engine and Exhaust

Bore / Stroke
95.0 x 72.0 mm / 3.7 x 2.8 inches
Engine Capacity
510.40 cc / 31.14 cubic inches
Engine Type
Single cylinder, four-stroke
Ignition
Keihin EMS
Starter
Electric & kick

Transmission (Gearbox) and Final Drive

Transmission Type
Chain
Gearbox
6-speed
Clutch
Wet, DDS multi-disc clutch, Brembo hydraulics
Drive line
5/8 x 1/4
Lubrication System
Pressure circulation lubrication with two rotary pumps

Fuel and Emission Standards

Fuel System
Injection
Fuel Control
Single Overhead Cams (SOHC)
Fuel Capacity
9.00 litres / 2.38 gallons

Suspension

Front Suspension
WP USD ? 48 mm
Front Wheel Travel
300 mm / 11.8 inches
Rear Suspension
WP Xplor PDS shock absorber
Rear Wheel Travel
310 mm / 12.2 inches

Tires and Rims

Rims
CNC machined hubs and high-end Giant rims

Brakes

Front Brakes
Single disc. Brake calipers on floating bearings
Front Brake Diameter
260 mm / 10.2 inches
Rear Brakes
Single disc. Brake calipers on floating bearings
Rear Brake Diameter
220 mm / 8.7 inches

Notes, Comments and Warranty Information

Colour Options
Orange/white/black
