KTM 450 SX-F 2013 specifications pictures and more for the 2013 KTM 450 SX-F in South Africa brought to you by Motomedia

KTM 450 SX-F 2013 motorcycle info

Main Detail

Make

KTM

Model

450 SX-F

Year

2013

Performance and Speed

Power to Weight Ratio

0.0815 HP/kg

Torque

9.20 Nm (0.9 kgf-m or 6.8 ft.lbs) @ 7000 Revolutions">RPM

Dimensions and Weight

Dry Weight

106.2 kg / 234.1 pounds

Ground Clearance

375 mm / 14.8 inches

Overall Height

1,140 mm / 44.9 inches

Overall Length

2,090 mm / 82.3 inches

Overall Width

830 mm / 32.7 inches

Wheelbase

1,495 mm / 58.9 inches

Engine and Exhaust

Bore / Stroke

95.0 x 63.4 mm / 3.7 x 2.5 inches

Engine Capacity

449.30 cc / 27.42 cubic inches

Compression

10.6:1

Engine Type

Single cylinder, four-stroke

Ignition

Contactless controlled fully electronic ignition with digital ignition adjustment

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

4-speed

Clutch

Multidisc clutch in oil bath/hydraulically activated

Drive line

5/8 x 1/4

Lubrication System

Pressure circulation lubrication with two Eaton pumps

Fuel and Emission Standards

Fuel System

Carburettor

Fuel Control

Single Overhead Cams (SOHC)

Fuel Capacity

7.50 litres / 1.98 gallons

Suspension

Front Suspension

WP ?Suspension Up Side Down 4860 MXMA CC

Front Suspension Travel

205 mm / 8.1 inches

Front Wheel Travel

205 mm / 8.1 inches

Rear Suspension

WP ?Suspension 5018 BAVP DCC

Rear Wheel Travel

185 mm / 7.3 inches

Tires and Rims

Front Tire

100/80-17

Rear Tire

110/80-17

Brakes

Front Brakes

Single disc. Four-piston calipers.

Front Brake Diameter

220 mm / 8.7 inches

Rear Brakes

Single disc. Two-piston calipers.

Rear Brake Diameter

210 mm / 8.3 inches

Notes, Comments and Warranty Information

Colour Options

Orange/black

KTM 450 SX-F 2013 specs
