KTM 300 EXC 2013 specifications pictures and more for the 2013 KTM 300 EXC in South Africa brought to you by Motomedia

KTM 300 EXC 2013 motorcycle info

Main Detail

Make

KTM

Model

300 EXC

Year

2013

Performance and Speed

Power to Weight Ratio

0.0815 HP/kg

Torque

9.20 Nm (0.9 kgf-m or 6.8 ft.lbs) @ 7000 Revolutions">RPM

Dimensions and Weight

Dry Weight

104.0 kg / 229.3 pounds

Ground Clearance

355 mm / 14.0 inches

Overall Height

1,140 mm / 44.9 inches

Overall Length

2,090 mm / 82.3 inches

Overall Width

830 mm / 32.7 inches

Wheelbase

1,482 mm / 58.3 inches

Engine and Exhaust

Bore / Stroke

72.0 x 72.0 mm / 2.8 x 2.8 inches

Engine Capacity

293.00 cc / 17.88 cubic inches

Compression

10.6:1

Engine Detail

Reed intake.

Engine Type

Single cylinder, two-stroke

Ignition

Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment, type Kokusan

Starter

Electric & kick

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Wet multi-disc clutch / hydraulically operated

Drive line

14:50 (13:50). Primary drive: 26:72.

Fuel and Emission Standards

Fuel System

Carburettor

Fuel Control

Single Overhead Cams (SOHC)

Fuel Capacity

9.50 litres / 2.51 gallons

Suspension

Front Suspension

WP ?Suspension Up Side Down 4860 MXMA PA

Front Suspension Travel

300 mm / 11.8 inches

Front Wheel Travel

300 mm / 11.8 inches

Rear Suspension

WP ?Suspension PDS 5018 DCC

Rear Wheel Travel

335 mm / 13.2 inches

Tires and Rims

Front Tire

100/80-17

Rear Tire

110/80-17

Brakes

Front Brakes

Single disc

Front Brake Diameter

280 mm / 11.0 inches

Rear Brakes

Single disc

Rear Brake Diameter

240 mm / 9.4 inches

Notes, Comments and Warranty Information

Colour Options

Orange/black

KTM 300 EXC 2013 specs
