KTM 300 EXC 2013 specifications pictures and more for the 2013 KTM 300 EXC in South Africa brought to you by Motomedia

KTM 300 EXC 2013 specs

Latest motor bike specifications and pictures for the 2013 KTM 300 EXC.



KTM 300 EXC 2013 motorcycle info

Main Detail

Make
KTM
Model
300 EXC
Year
2013
Category
Enduro / Off-Road

Performance and Speed

Power to Weight Ratio
0.0815 HP/kg
Torque
9.20 Nm (0.9 kgf-m or 6.8 ft.lbs) @ 7000 Revolutions">RPM

Dimensions and Weight

Dry Weight
104.0 kg / 229.3 pounds
Ground Clearance
355 mm / 14.0 inches
Overall Height
1,140 mm / 44.9 inches
Overall Length
2,090 mm / 82.3 inches
Overall Width
830 mm / 32.7 inches
Wheelbase
1,482 mm / 58.3 inches

Engine and Exhaust

Bore / Stroke
72.0 x 72.0 mm / 2.8 x 2.8 inches
Engine Capacity
293.00 cc / 17.88 cubic inches
Compression
10.6:1
Engine Detail
Reed intake.
Engine Type
Single cylinder, two-stroke
Ignition
Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment, type Kokusan
Starter
Electric & kick
Valves / Cylinder
2

Transmission (Gearbox) and Final Drive

Transmission Type
Chain
Gearbox
6-speed
Clutch
Wet multi-disc clutch / hydraulically operated
Drive line
14:50 (13:50). Primary drive: 26:72.

Fuel and Emission Standards

Fuel System
Carburettor
Fuel Control
Single Overhead Cams (SOHC)
Fuel Capacity
9.50 litres / 2.51 gallons

Suspension

Front Suspension
WP ?Suspension Up Side Down 4860 MXMA PA
Front Suspension Travel
300 mm / 11.8 inches
Front Wheel Travel
300 mm / 11.8 inches
Rear Suspension
WP ?Suspension PDS 5018 DCC
Rear Wheel Travel
335 mm / 13.2 inches

Tires and Rims

Front Tire
100/80-17
Rear Tire
110/80-17

Brakes

Front Brakes
Single disc
Front Brake Diameter
280 mm / 11.0 inches
Rear Brakes
Single disc
Rear Brake Diameter
240 mm / 9.4 inches

Notes, Comments and Warranty Information

Colour Options
Orange/black
