KTM 200 XC-W 2014 specifications pictures and more for the 2014 KTM 200 XC-W in South Africa brought to you by Motomedia

KTM 200 XC-W 2014 specs

Latest motor bike specifications and pictures for the 2014 KTM 200 XC-W.



KTM 200 XC-W 2014 motorcycle info

Main Detail

Make
KTM
Model
200 XC-W
Year
2014
Category
Enduro / Off-Road

Performance and Speed

Top Speed
45.1 km/h / 28.0 mph

Dimensions and Weight

Dry Weight
99.5 kg / 219.4 pounds
Ground Clearance
355 mm / 14.0 inches
Overall Height
1,120 mm / 44.1 inches
Overall Length
2,120 mm / 83.5 inches
Overall Width
840 mm / 33.1 inches
Kerb Weight
112.0 kg / 246.9 pounds
Wheelbase
1,471 mm / 57.9 inches

Engine and Exhaust

Bore / Stroke
64.0 x 60.0 mm / 2.5 x 2.4 inches
Engine Capacity
193.00 cc / 11.78 cubic inches
Engine Detail
Reed intake.
Engine Type
Single cylinder, two-stroke
Ignition
Contactless controlled fully electronic ignition with digital ignition adjustment, type Kokusan
Starter
Electric & kick
Exhaust system
Stainless steel exhaust

Transmission (Gearbox) and Final Drive

Transmission Type
Chain
Gearbox
6-speed
Clutch
Multidisc clutch in oil bath/hydraulically activated
Drive line
5/8 x 1/4

Fuel and Emission Standards

Fuel System
Carburettor
Fuel Capacity
10.00 litres / 2.64 gallons
Emission Details
Euro 2

Suspension

Front Suspension
WP ?Suspension Up Side Down 4860 MXMA PA
Front Suspension Travel
300 mm / 11.8 inches
Front Wheel Travel
300 mm / 11.8 inches
Rear Suspension
WP ?Suspension PDS 5018 DCC
Rear Wheel Travel
335 mm / 13.2 inches

Tires and Rims

Front Tire
110/70-17
Rear Tire
130/70-17

Brakes

Front Brakes
Single disc. Brake calipers on floating bearings
Front Brake Diameter
260 mm / 10.2 inches
Rear Brakes
Single disc. Brake calipers on floating bearings
Rear Brake Diameter
220 mm / 8.7 inches

Instrumentation and Lighting

Instruments
Digital cockpit

Notes, Comments and Warranty Information

Comments
German brand.
Colour Options
Orange/black
