KTM 150 XC-W 2017 specifications pictures and more for the 2017 KTM 150 XC-W in South Africa brought to you by Motomedia

KTM 150 XC-W 2017 motorcycle info

Main Detail

Make

KTM

Model

150 XC-W

Year

2017

Dimensions and Weight

Dry Weight

91.5 kg / 201.7 pounds

Ground Clearance

370 mm / 14.6 inches

Wheelbase

1,471 mm / 57.9 inches

Engine and Exhaust

Bore / Stroke

58.0 x 54.5 mm / 2.3 x 2.1 inches

Engine Capacity

143.90 cc / 8.78 cubic inches

Engine Detail

Reed intake.

Engine Type

Single cylinder, two-stroke

Ignition

Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment, type Kokusan

Starter

Kick

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Multi-plate clutch, Brembo hydraulics

Drive line

14:50. Primary drive: 23:73.

Fuel and Emission Standards

Fuel System

Carburettor

Fuel Capacity

9.50 litres / 2.51 gallons

Suspension

Front Suspension

WP XPlor 48 upside-down fork

Front Wheel Travel

300 mm / 11.8 inches

Rear Suspension

WP Xplor PDS shock absorber

Rear Wheel Travel

310 mm / 12.2 inches

Brakes

Front Brakes

Single disc. Four-piston calipers.

Front Brake Diameter

260 mm / 10.2 inches

Rear Brakes

Single disc. Two-piston calipers.

Rear Brake Diameter

220 mm / 8.7 inches

Notes, Comments and Warranty Information

Colour Options

Orange/white/black

KTM 150 XC-W 2017 specs
