KTM 1190 Adventure 2014 specifications pictures and more for the 2014 KTM 1190 Adventure in South Africa brought to you by Motomedia

KTM 1190 Adventure 2014 specs

Motomedia / Motorcycle makes / 2014 KTM specs || KTM 1190 Adventure 2014 specs
Latest motor bike specifications and pictures for the 2014 KTM 1190 Adventure.



KTM 1190 Adventure 2014 motorcycle info

Main Detail

Make
KTM
Model
1190 Adventure
Year
2014
Category
All-Round

Performance and Speed

Power to Weight Ratio
0.6958 HP/kg
Top Speed
45.1 km/h / 28.0 mph

Dimensions and Weight

Dry Weight
212.0 kg / 467.4 pounds
Ground Clearance
220 mm / 8.7 inches
Overall Height
1,120 mm / 44.1 inches
Overall Length
2,120 mm / 83.5 inches
Overall Width
840 mm / 33.1 inches
Kerb Weight
112.0 kg / 246.9 pounds
Wheelbase
1,560 mm / 61.4 inches

Engine and Exhaust

Bore / Stroke
105.0 x 69.0 mm / 4.1 x 2.7 inches
Engine Capacity
1195.00 cc / 72.92 cubic inches
Engine Type
Twin, four-stroke
Ignition
Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment
Starter
Electric
Exhaust system
Stainless steel exhaust

Transmission (Gearbox) and Final Drive

Transmission Type
Chain
Gearbox
6-speed
Clutch
PASC anti-hopping clutch/ hydraulically operated
Drive line
5/8 x 5/16 X Ring. Primary drive: 40:76.
Lubrication System
Forced oil lubrication with 3 rotor pumps

Fuel and Emission Standards

Fuel System
Injection
Fuel Capacity
23.00 litres / 6.08 gallons
Emission Details
Euro 2

Suspension

Front Suspension
WP ?Suspension Up Side Down
Front Suspension Travel
190 mm / 7.5 inches
Front Wheel Travel
190 mm / 7.5 inches
Rear Suspension
WP ?Suspension monoshock
Rear Wheel Travel
190 mm / 7.5 inches

Tires and Rims

Front Tire
110/70-17
Rear Tire
130/70-17

Brakes

Front Brakes
Double disc. Four-piston calipers. Radially mounted.
Front Brake Diameter
320 mm / 12.6 inches
Rear Brakes
Single disc. Two-piston calipers.
Rear Brake Diameter
267 mm / 10.5 inches

Instrumentation and Lighting

Instruments
Digital cockpit

Notes, Comments and Warranty Information

Comments
Small windscreen. Ride-by-wire system.
Colour Options
White, Orange
