Kawasaki Ninja ZX-14R 2013 specifications pictures and more for the 2013 Kawasaki Ninja ZX-14R in South Africa brought to you by Motomedia

Kawasaki Ninja ZX-14R 2013 motorcycle info

Main Detail

Make

Kawasaki

Model

Ninja ZX-14R

Year

2013

Performance and Speed

Torque

8.00 Nm (0.8 kgf-m or 5.9 ft.lbs)

Dimensions and Weight

Ground Clearance

124 mm / 4.9 inches

Overall Height

1,171 mm / 46.1 inches

Overall Length

2,169 mm / 85.4 inches

Overall Width

770 mm / 30.3 inches

Trail

94 mm / 3.7 inches

Kerb Weight

265.0 kg / 584.3 pounds

Wheelbase

1,481 mm / 58.3 inches

Engine and Exhaust

Bore / Stroke

84.0 x 65.0 mm / 3.3 x 2.6 inches

Engine Capacity

1441.00 cc / 87.93 cubic inches

Compression

12.3:1

Engine Detail

Reed valve.

Engine Type

In-line four, four-stroke

Ignition

TCBI with Digital Advance

Starter

Electric

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Centrifugal, wet multi-disc

Drive line

X-Ring Chain

Lubrication System

Forced lubrication, wet sump

Fuel and Emission Standards

Fuel System

Injection. DFI with four 44mm Mikuni throttle bodies

Fuel Control

DOHC

Fuel Capacity

21.95 litres / 5.80 gallons

Suspension

Front Suspension

43mm inverted cartridge fork with adjustable preload, 18-way compression and 15-way rebound damping adjustment / 4.6 in.

Rear Suspension

Bottom-link Uni-Trak and gas-charged shock with adjustable preload, stepless rebound and compression damping adjustments, adjustable ride height / 4.9 in.

Tires and Rims

Front Tire

2.50-14

Front Tire Dimensions

120/70-ZR17

Rear Tire

3.00-12

Rear Tire Dimensions

190/50-ZR17

Brakes

Front Brakes

Double disc. Petal discs with dual radial-mounted four-piston calipers and optional ABS

Front Brake Diameter

310 mm / 12.2 inches

Rear Brakes

Single disc. Petal disc with twin-piston caliper and optional ABS

Rear Brake Diameter

250 mm / 9.8 inches

Notes, Comments and Warranty Information

Factory Warranty

12 months

Colour Options

Passion Red, Pearl Flat White, Metallic Spark Black/Golden Blazed Green (SE)

Kawasaki Ninja ZX-14R 2013 specs
