Kawasaki Ninja H2 2016 specifications pictures and more for the 2016 Kawasaki Ninja H2 in South Africa brought to you by Motomedia

Kawasaki Ninja H2 2016 motorcycle info

Main Detail

Make

Kawasaki

Model

Ninja H2

Year

2016

Performance and Speed

Torque

133.00 Nm (13.6 kgf-m or 98.1 ft.lbs) @ 10500 Revolutions">RPM

Dimensions and Weight

Ground Clearance

130 mm / 5.1 inches

Overall Height

1,125 mm / 44.3 inches

Overall Length

2,085 mm / 82.1 inches

Overall Width

770 mm / 30.3 inches

Trail

104 mm / 4.1 inches

Kerb Weight

238.1 kg / 524.8 pounds

Wheelbase

1,455 mm / 57.3 inches

Engine and Exhaust

Bore / Stroke

76.0 x 55.0 mm / 3.0 x 2.2 inches

Compression

8.5:1

Engine Detail

Kawasaki supercharger intake system

Engine Type

In-line four, four-stroke

Ignition

Digital

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Lubrication System

Forced lubrication, wet sump with oil cooler

Fuel and Emission Standards

Fuel System

Injection. DFI 50mm throttle bodies x 4 with dual injection

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Capacity

17.03 litres / 4.50 gallons

Suspension

Front Suspension

43mm inverted fork with rebound and compression damping, spring preload adjustability and top-out springs

Front Wheel Travel

119 mm / 4.7 inches

Rear Suspension

Uni-Trak with gas-charged shock, piggyback reservoir, dual-range (high/low speed) compression damping, rebound damping and preload adjustability, and top-out spring

Rear Wheel Travel

135 mm / 5.3 inches

Tires and Rims

Front Tire

120/70-ZR17

Rear Tire

200/55-ZR17

Brakes

Front Brakes

Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted.

Front Brake Diameter

330 mm / 13.0 inches

Rear Brakes

Single disc. ABS. Two-piston calipers.

Rear Brake Diameter

250 mm / 9.8 inches

Notes, Comments and Warranty Information

Comments

154.5 kW (210 PS) at 11.000 rpm with RAM air.

Factory Warranty

12 month Limited Warranty

Colour Options

Mirror Coated Black

Kawasaki Ninja H2 2016 specs
