Honda XR150L 2016 specifications pictures and more for the 2016 Honda XR150L in South Africa brought to you by Motomedia

Honda XR150L 2016 motorcycle info

Main Detail

Make

Honda

Model

XR150L

Year

2016

Dimensions and Weight

Dry Weight

130.0 kg / 286.6 pounds

Ground Clearance

245 mm / 9.6 inches

Overall Height

1,125 mm / 44.3 inches

Overall Length

2,090 mm / 82.3 inches

Overall Width

810 mm / 31.9 inches

Wheelbase

1,390 mm / 54.7 inches

Engine and Exhaust

Bore / Stroke

57.3 x 57.8 mm / 2.3 x 2.3 inches

Engine Capacity

149.00 cc / 9.09 cubic inches

Compression

9.5:1

Engine Type

Single cylinder, four-stroke

Starter

Electric & kick

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

5-speed

Fuel and Emission Standards

Fuel System

Carburettor. 20mm piston-valve

Fuel Control

Overhead Valves (OHV)

Fuel Capacity

12.00 litres / 3.17 gallons

Suspension

Front Suspension

Telescopic fork

Front Wheel Travel

160 mm / 6.3 inches

Rear Suspension

Swingarm, single shock

Rear Wheel Travel

151 mm / 5.9 inches

Carrying Capacity

Rear rack

Tires and Rims

Front Tire

90/90-19

Rear Tire

110/90-17

Brakes

Front Brakes

Single disc. Dual-piston calliper

Front Brake Diameter

240 mm / 9.4 inches

Rear Brakes

Expanding brake (drum brake)

Notes, Comments and Warranty Information

Comments

Sold as a farm bike in Australia and Asia.

Colour Options

Red

Honda XR150L 2016 specs
