Honda XR150L 2016 specifications pictures and more for the 2016 Honda XR150L in South Africa brought to you by Motomedia

Honda XR150L 2016 specs

Latest motor bike specifications and pictures for the 2016 Honda XR150L.



Honda XR150L 2016 motorcycle info

Main Detail

Make
Honda
Model
XR150L
Year
2016
Category
Enduro / Off-Road

Dimensions and Weight

Dry Weight
130.0 kg / 286.6 pounds
Ground Clearance
245 mm / 9.6 inches
Overall Height
1,125 mm / 44.3 inches
Overall Length
2,090 mm / 82.3 inches
Overall Width
810 mm / 31.9 inches
Wheelbase
1,390 mm / 54.7 inches

Engine and Exhaust

Bore / Stroke
57.3 x 57.8 mm / 2.3 x 2.3 inches
Engine Capacity
149.00 cc / 9.09 cubic inches
Compression
9.5:1
Engine Type
Single cylinder, four-stroke
Starter
Electric & kick
Valves / Cylinder
4

Transmission (Gearbox) and Final Drive

Transmission Type
Chain
Gearbox
5-speed

Fuel and Emission Standards

Fuel System
Carburettor. 20mm piston-valve
Fuel Control
Overhead Valves (OHV)
Fuel Capacity
12.00 litres / 3.17 gallons

Suspension

Front Suspension
Telescopic fork
Front Wheel Travel
160 mm / 6.3 inches
Rear Suspension
Swingarm, single shock
Rear Wheel Travel
151 mm / 5.9 inches
Carrying Capacity
Rear rack

Tires and Rims

Front Tire
90/90-19
Rear Tire
110/90-17

Brakes

Front Brakes
Single disc. Dual-piston calliper
Front Brake Diameter
240 mm / 9.4 inches
Rear Brakes
Expanding brake (drum brake)

Notes, Comments and Warranty Information

Comments
Sold as a farm bike in Australia and Asia.
Colour Options
Red
