Honda VTX 1300 2006 specifications pictures and more for the 2006 Honda VTX 1300 in South Africa brought to you by Motomedia

Honda VTX 1300 2006 motorcycle info

Main Detail

Make

Honda

Model

VTX 1300

Year

2006

Dimensions and Weight

Dry Weight

290.8 kg / 641.0 pounds

Trail

149 mm / 5.9 inches

Wheelbase

1,637 mm / 64.5 inches

Engine and Exhaust

Bore / Stroke

89.5 x 104.3 mm / 3.5 x 4.1 inches

Engine Capacity

1312.00 cc / 80.06 cubic inches

Compression

9.2:1

Engine Type

Ignition

Digital with three-dimensional mapping, two spark plugs per cylinder

2 / 4 Stroke

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Shaft drive (cardan)

Gearbox

5-speed

Fuel and Emission Standards

Fuel System

Carburettor. Single 38mm CV

Fuel Control

SOHC

Fuel Capacity

18.16 litres / 4.80 gallons

Suspension

Front Suspension

41mm fork

Front Suspension Travel

130 mm / 5.1 inches

Front Wheel Travel

130 mm / 5.1 inches

Rear Suspension

Dual shocks with five-position spring-preload adjustability

Rear Wheel Travel

91 mm / 3.6 inches

Tires and Rims

Front Tire Dimensions

110/90-M19

Rear Tire Dimensions

170/80-M15

Brakes

Front Brakes

Single disc

Front Brake Diameter

336 mm / 13.2 inches

Rear Brakes

Single disc

Rear Brake Diameter

296 mm / 11.7 inches

Notes, Comments and Warranty Information

Colour Options

Black, Candy Black Cherry, Candy Orange, Dark Gray Metallic

Honda VTX 1300 2006 specs
