Honda CRF110F 2014 specifications pictures and more for the 2014 Honda CRF110F in South Africa brought to you by Motomedia

Honda CRF110F 2014 motorcycle info

Main Detail

Make

Honda

Model

CRF110F

Year

2014

Performance and Speed

Torque

8.85 Nm (0.9 kgf-m or 6.5 ft.lbs) @ 3500

Dimensions and Weight

Ground Clearance

175 mm / 6.9 inches

Overall Height

912 mm / 35.9 inches

Overall Length

1,560 mm / 61.4 inches

Overall Width

668 mm / 26.3 inches

Trail

53 mm / 2.1 inches

Kerb Weight

73.9 kg / 163.0 pounds

Wheelbase

1,064 mm / 41.9 inches

Engine and Exhaust

Bore / Stroke

50.0 x 55.6 mm / 2.0 x 2.2 inches

Engine Capacity

109.00 cc / 6.65 cubic inches

Compression

9.0:1

Engine Type

Single cylinder, four-stroke

Ignition

CDI

Starter

Electric & kick

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

4-speed

Drive line

#428 chain; 14T/50T

Fuel and Emission Standards

Fuel System

Carburettor. 13mm piston-valve carburetor

Fuel Control

SOHC

Fuel Capacity

4.16 litres / 1.10 gallons

Reserve Fuel Capacity

1.00 litres / 0.26 gallons

Emission Details

Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.

Suspension

Front Suspension

31.0mm telescopic fork

Front Suspension Travel

90 mm / 3.5 inches

Front Wheel Travel

90 mm / 3.5 inches

Rear Suspension

Single-shock

Rear Wheel Travel

96 mm / 3.8 inches

Tires and Rims

Front Tire

2.50-19

Front Tire Dimensions

70/100-14

Rear Tire

3.00-16

Rear Tire Dimensions

80/100-12

Brakes

Front Brakes

Expanding brake (drum brake)

Front Brake Diameter

109 mm / 4.3 inches

Rear Brakes

Expanding brake (drum brake)

Rear Brake Diameter

109 mm / 4.3 inches

Notes, Comments and Warranty Information

Comments

Model ID: CRF110F

Factory Warranty

Six Months transferable limited warranty; extended warranty available with a Honda Protection Plan.

Colour Options

Red

Honda CRF110F 2014 specs
