Honda CBR600RR 2016 specifications pictures and more for the 2016 Honda CBR600RR in South Africa brought to you by Motomedia

Honda CBR600RR 2016 motorcycle info

Main Detail

Make

Honda

Model

CBR600RR

Year

2016

Performance and Speed

Torque

66.00 Nm (6.7 kgf-m or 48.7 ft.lbs) @ 11225 Revolutions">RPM

Dimensions and Weight

Overall Length

2,029 mm / 79.9 inches

Trail

98 mm / 3.8 inches

Kerb Weight

186.0 kg / 410.0 pounds

Wheelbase

1,373 mm / 54.1 inches

Engine and Exhaust

Bore / Stroke

67.0 x 42.5 mm / 2.6 x 1.7 inches

Compression

12.2:1

Engine Type

In-line four, four-stroke

Ignition

Computer-controlled digital transistorized with 3-D mapping

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Drive line

#525 O-ring chain

Fuel and Emission Standards

Fuel System

Injection. Dual Stage Fuel Injection (DSFI) with 40mm throttle bodies, Denso 12-hole injectors

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Capacity

18.17 litres / 4.80 gallons

Emission Details

Meets current EPA standards. California version meets current CARB standards and may differ slightly due to emissions equipment.

Suspension

Front Suspension

41mm inverted Big Piston Fork with spring preload, rebound and compression damping adjustability

Rear Suspension

Unit Pro-Link HMAS single shock with spring preload, rebound and compression damping adjustability

Tires and Rims

Front Tire

120/70-ZR17

Rear Tire

180/55-ZR17

Rims

Hollow section 12 spoke cast aluminium

Brakes

Front Brakes

Double disc. Floating discs. Four-piston calipers. Radially mounted.

Front Brake Diameter

310 mm / 12.2 inches

Rear Brakes

Single disc. Single-piston caliper.

Rear Brake Diameter

220 mm / 8.7 inches

Instrumentation and Lighting

Instruments

LCD Instrumentation.

Notes, Comments and Warranty Information

Comments

Model ID: CBR600RR

Factory Warranty

One year. Unlimited milage. Transferable.

Colour Options

Black/White

Honda CBR600RR 2016 specs
