Honda CBR125R 2014 specifications pictures and more for the 2014 Honda CBR125R in South Africa brought to you by Motomedia

Honda CBR125R 2014 motorcycle info

Main Detail

Make

Honda

Model

CBR125R

Year

2014

Performance and Speed

Power to Weight Ratio

0.0942 HP/kg

Torque

10.60 Nm (1.1 kgf-m or 7.8 ft.lbs)

Dimensions and Weight

Dry Weight

138.0 kg / 304.2 pounds

Ground Clearance

135 mm / 5.3 inches

Overall Height

1,175 mm / 46.3 inches

Overall Length

1,920 mm / 75.6 inches

Overall Width

675 mm / 26.6 inches

Kerb Weight

250.0 kg / 551.2 pounds

Wheelbase

1,070 mm / 42.1 inches

Engine and Exhaust

Bore / Stroke

75.0 x 56.5 mm / 3.0 x 2.2 inches

Engine Capacity

124.70 cc / 7.61 cubic inches

Compression

11.0:1

Engine Type

Single cylinder, four-stroke

Ignition

Computer-controlled digital transistorised with electronic advance?

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Wet, multiplate, mechanical cable-actuated.

Drive line

O-ring sealed chain

Lubrication System

Forced pressure and wet sump

Fuel and Emission Standards

Fuel System

Injection

Fuel Control

SOHC

Fuel Capacity

10.00 litres / 2.64 gallons

Reserve Fuel Capacity

4.00 litres / 1.06 gallons

Suspension

Front Suspension

Telescopic

Front Wheel Travel

120 mm / 4.7 inches

Rear Suspension

Monshock

Rear Wheel Travel

120 mm / 4.7 inches

Tires and Rims

Front Tire

120/70-ZR17

Front Tire Dimensions

80/90-17

Rear Tire

160/60-ZR17

Rear Tire Dimensions

100/80-17

Rims

U-section 6-spoke cast aluminium

Brakes

Front Brakes

Single disc

Front Brake Diameter

296 mm / 11.7 inches

Rear Brakes

Single disc

Rear Brake Diameter

240 mm / 9.4 inches

Notes, Comments and Warranty Information

Colour Options

Red, White, Red/black/orange, Red/white/blue
