Honda CBR1000RR 2014 specifications pictures and more for the 2014 Honda CBR1000RR in South Africa brought to you by Motomedia

Honda CBR1000RR 2014 motorcycle info

Main Detail

Make

Honda

Model

CBR1000RR

Year

2014

Performance and Speed

Torque

96.00 Nm (9.8 kgf-m or 70.8 ft.lbs) @ 6500 Revolutions">RPM

Dimensions and Weight

Dry Weight

320.0 kg / 705.5 pounds

Ground Clearance

135 mm / 5.3 inches

Overall Height

1,175 mm / 46.3 inches

Overall Length

2,176 mm / 85.7 inches

Trail

96 mm / 3.8 inches

Kerb Weight

200.0 kg / 440.9 pounds

Wheelbase

1,410 mm / 55.5 inches

Engine and Exhaust

Bore / Stroke

76.0 x 55.1 mm / 3.0 x 2.2 inches

Engine Capacity

999.00 cc / 60.96 cubic inches

Compression

12.3:1

Engine Type

In-line four, four-stroke

Ignition

Computer-controlled digital transistorized with 3-D mapping

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Drive line

#530 O-ring-sealed chain

Fuel and Emission Standards

Fuel System

Injection. Programmed Dual Stage Fuel Injection (PGM-DSFI) with 46mm throttle bodies, Denso 12-hole injectors

Fuel Control

DOHC

Fuel Consumption

5.74 litres/100 km (17.4 km/l or 40.98 mpg)

Fuel Capacity

17.79 litres / 4.70 gallons

Reserve Fuel Capacity

4.00 litres / 1.06 gallons

Emission Details

Meets current EPA standards. California version meets current CARB standards and may differ slightly due to emissions equipment.

Greenhouse Gases

133.2 CO

Suspension

Front Suspension

43mm inverted Big Piston fork with spring preload, rebound and compression damping adjustability

Front Suspension Travel

109 mm / 4.3 inches

Front Wheel Travel

120 mm / 4.7 inches

Rear Suspension

Unit Pro-Link Balance Free Rear Shock with spring preload, rebound and compression-damping adjustability

Rear Wheel Travel

120 mm / 4.7 inches

Tires and Rims

Front Tire

120/70-ZR17

Front Tire Dimensions

120/70-ZR17

Rear Tire

160/60-ZR17

Rear Tire Dimensions

190/50-ZR17

Rims

Hollow-section 6-spoke cast aluminium

Brakes

Front Brakes

Double disc. Floating discs. Four-piston calipers. Radially mounted.

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc. Single-piston caliper.

Rear Brake Diameter

220 mm / 8.7 inches

Instrumentation and Lighting

Instruments

LCD Instrumentation.

Notes, Comments and Warranty Information

Comments

Model ID: CBR1000RR

Factory Warranty

One year. Unlimited milage. Transferable.

Colour Options

Black, Pearl White

Honda CBR1000RR 2014 specs
