Honda CB500F 2023 specifications pictures and more for the 2023 Honda CB500F in South Africa brought to you by Motomedia

Honda CB500F 2023 motorcycle info

Main Detail

Make

Honda

Model

CB500F

Year

2023

Performance and Speed

Power to Weight Ratio

0.2445 HP/kg

Torque

43.0 Nm (4.4 kgf-m or 31.7 ft.lbs) @ 6500 Revolutions">RPM

Dimensions and Weight

Dry Weight

192.0 kg / 423.3 pounds

Ground Clearance

145 mm / 5.7 inches

Overall Height

1060 mm / 41.7 inches

Overall Length

2080 mm / 81.9 inches

Overall Width

800 mm / 31.5 inches

Trail

102 mm / 4.0 inches

Kerb Weight

189.0 kg / 416.7 pounds

Wheelbase

1410 mm / 55.5 inches

Engine and Exhaust

Bore / Stroke

67.0 x 66.8 mm / 2.6 x 2.6 inches

Engine Capacity

471.0 cc / 28.74 cubic inches

Compression

10.7:1

Engine Type

Twin, four-stroke

Ignition

Computer-controlled digital transistorized with electronic advance

Spark Plugs

NGK CPR8EA-9

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain (final drive)

Gearbox

6-speed

Clutch

Wet multiplate, assist/slipper clutch

Drive line

O-ring-sealed chain; 15T/41T

Oil Capacity

2.70 litres / 2.85 US quarts

Coolant

2.00 litres (0.53 US gallons)

Sprockets

15/41 (front/rear)

Chain Size

520

Chain Links

112

Fuel and Emission Standards

Fuel System

Injection. PGM-FI with 34mm throttle bodies

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Consumption

3.50 litres/100 km (28.6 km/l or 67.21 mpg)

Fuel Capacity

16.70 litres / 4.41 US gallons

Emission Details

Euro 5

Greenhouse Gases

81.2 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

Showa 41mm SFF-BP USD forks

Front Wheel Travel

120 mm / 4.7 inches

Fork Tube Size

41 mm / 1.6 inches

Rear Suspension

Pro-Link® single shock with nine-position spring-preload adjustability

Rear Wheel Travel

119 mm / 4.7 inches

Tires and Rims

Front Tire

120/70-R17

Tire Pressure Front

36 PSI (2.5 Bar or 250 kPa)

Tire Pressure Rear

42 PSI (2.9 Bar or 290 kPa)

Brakes

Front Brakes

Single disc. ABS. 4-piston calipers.

Rear Brakes

Single disc. ABS.

Brake Fluid

DOT 4

Instrumentation and Lighting

Instruments

LCD Meter with Speedometer, Bar Graph Tachometer, Dual Trip Meters, Fuel Level and Consumption Gauge, Clock, Water Temp, Gear position, Shift UP Indicator

Lighting

Full LED lighting

Notes, Comments and Warranty Information

Comments

Security system. Noise Level L-urban: 74dB L-wot: 76.4dB. Model id: CB500FA.

Factory Warranty

One year. Transferable. Unlimited-mileage.

Colour Options

Matte Grey Metallic
