Honda CB1100 2013 specifications pictures and more for the 2013 Honda CB1100 in South Africa brought to you by Motomedia

Honda CB1100 2013 motorcycle info

Main Detail

Make

Honda

Model

CB1100

Year

2013

Performance and Speed

Torque

3.60 Nm (0.4 kgf-m or 2.7 ft.lbs) @ 6000 Revolutions">RPM

Dimensions and Weight

Ground Clearance

155 mm / 6.1 inches

Overall Height

1,155 mm / 45.5 inches

Overall Length

1,715 mm / 67.5 inches

Overall Width

780 mm / 30.7 inches

Trail

107 mm / 4.2 inches

Kerb Weight

82.0 kg / 180.8 pounds

Wheelbase

1,491 mm / 58.7 inches

Engine and Exhaust

Bore / Stroke

73.5 x 67.2 mm / 2.9 x 2.6 inches

Engine Capacity

1140.00 cc / 69.56 cubic inches

Compression

9.5:1

Engine Detail

Honda AC16E engine

Engine Type

In-line four, four-stroke

Ignition

Digital transistorized with electronic advance

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

5-speed

Clutch

Wet, multiplate

Drive line

#530 O-ring-sealed chain

Fuel and Emission Standards

Fuel System

Injection. PGM-FI with automatic enrichment circuit, 32mm throttle bodies

Fuel Control

DOHC

Fuel Consumption

1.08 litres/100 km (92.6 km/l or 217.80 mpg)

Fuel Capacity

14.76 litres / 3.90 gallons

Emission Details

Meets current EPA standards. California version meets current CARB standards and may differ slightly due to emissions equipment.

Greenhouse Gases

25.1 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

41mm fork with spring preload adjustability

Rear Suspension

Dual shocks with spring preload adjustability

Tires and Rims

Front Tire

120/80-12

Front Tire Dimensions

110/80-18

Rear Tire

120/80-12

Rear Tire Dimensions

140/70-18

Brakes

Front Brakes

Double disc. Floating discs. Four-piston calipers.

Front Brake Diameter

296 mm / 11.7 inches

Rear Brakes

Single disc. Single-piston.

Rear Brake Diameter

256 mm / 10.1 inches

Notes, Comments and Warranty Information

Comments

Model ID: CB1100

Factory Warranty

One year. Unlimited milage. Transferable.

Colour Options

Candy Red

Honda CB1100 2013 specs
