Honda CB1000R 2011 motorcycle info

Main Detail

Make

Honda

Model

CB1000R

Year

2011

Dimensions and Weight

Dry Weight

220.0 kg / 485.0 pounds

Ground Clearance

127 mm / 5.0 inches

Overall Width

1,016 mm / 40.0 inches

Trail

99 mm / 3.9 inches

Wheelbase

1,445 mm / 56.9 inches

Engine and Exhaust

Bore / Stroke

75.0 x 56.5 mm / 3.0 x 2.2 inches

Engine Capacity

998.00 cc / 60.90 cubic inches

Compression

11.2:1

Engine Type

In-line four, four-stroke

Ignition

Computer-controlled digital transistorized with 3-D mapping

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Wet, multiplate

Drive line

#530 0-ring chain

Fuel and Emission Standards

Fuel System

Injection. PGM-FI Fuel injection with automatic enrichment circuit and 36mm throttle bodies

Fuel Control

DOHC

Fuel Capacity

17.03 litres / 4.50 gallons

Emission Details

Meets current EPA standards. Models sold in California meet current CARB standards and may differ slightly due to emissions equipment.

Suspension

Front Suspension

43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability

Front Suspension Travel

119 mm / 4.7 inches

Front Wheel Travel

300 mm / 11.8 inches

Rear Suspension

Single gas-charged HMAS shock with spring preload and rebound damping adjustability

Rear Wheel Travel

127 mm / 5.0 inches

Tires and Rims

Front Tire Dimensions

120/70-ZR17

Rear Tire Dimensions

180/55-ZR17

Brakes

Front Brakes

Double disc

Front Brake Diameter

310 mm / 12.2 inches

Rear Brakes

Single disc

Rear Brake Diameter

256 mm / 10.1 inches

Notes, Comments and Warranty Information

Modifications from Previous Model

Also called USHighland 507 ATX QuadRacer.

Colour Options

Pearl Black

Honda CB1000R 2011 specs
