Honda CB1000R 2009 specifications pictures and more for the 2009 Honda CB1000R in South Africa brought to you by Motomedia

Honda CB1000R 2009 motorcycle info

Main Detail

Make

Honda

Model

CB1000R

Year

2009

Performance and Speed

Power to Weight Ratio

0.5685 HP/kg

Torque

100.00

Dimensions and Weight

Dry Weight

217.0 kg / 478.4 pounds

Ground Clearance

130 mm / 5.1 inches

Overall Height

2,105 mm / 82.9 inches

Overall Length

2,105 mm / 82.9 inches

Wheelbase

1,445 mm / 56.9 inches

Engine and Exhaust

Bore / Stroke

75.0 x 56.5 mm / 3.0 x 2.2 inches

Engine Capacity

998.00 cc / 60.90 cubic inches

Compression

11.2:1

Engine Type

In-line four

Ignition

Computer-controlled digital transistorised with electronic advance

Starter

Electric

2 / 4 Stroke

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Fuel and Emission Standards

Fuel System

Injection. PGM-FI electronic fuel injection

Fuel Control

DOHC

Fuel Capacity

17.00 litres / 4.49 gallons

Suspension

Front Suspension

43mm inverted HMAS cartridge-type telescopic fork with stepless preload, compression and rebound adjustment, 120mm cushion stroke

Rear Suspension

Monoshock with gas-charged HMAS damper featuring 10-step preload and stepless rebound damping adjustment, 128mm axle travel

Tires and Rims

Front Tire Dimensions

120/70-ZR17

Rear Tire Dimensions

180/55-ZR17

Brakes

Front Brakes

Double disc

Front Brake Diameter

310 mm / 12.2 inches

Rear Brakes

Single disc

Rear Brake Diameter

256 mm / 10.1 inches

Notes, Comments and Warranty Information

Colour Options

Olive, gray, black, white

Honda CB1000R 2009 specs
