Harley-Davidson Street Bob 114 2021 motorcycle info

Main Detail

Make

Harley-Davidson

Model

Street Bob 114

Year

2021

Performance and Speed

Torque

161.4 Nm (16.5 kgf-m or 119.0 ft.lbs) @ 3000 Revolutions">RPM

Dimensions and Weight

Dry Weight

287.6 kg / 634.0 pounds

Ground Clearance

125 mm / 4.9 inches

Overall Length

2320 mm / 91.3 inches

Trail

157 mm / 6.2 inches

Kerb Weight

298.9 kg / 659.0 pounds

Wheelbase

1630 mm / 64.2 inches

Engine and Exhaust

Bore / Stroke

102.0 x 114.3 mm / 4.0 x 4.5 inches

Engine Capacity

1868.2 cc / 114.00 cubic inches

Compression

10.5:1

Engine Detail

Milwaukee-Eight® 114

Engine Type

V2, four-stroke

Starter

Electric

Exhaust system

2-into-2 offset shotgun; catalyst in muffler

Transmission (Gearbox) and Final Drive

Transmission Type

Belt (final drive)

Gearbox

6-speed

Clutch

Multi-plate with diaphragm spring in oil bath

Drive line

Chain 34/46 ratio primary drive

Oil Capacity

4.70 litres / 4.97 US quarts

Fuel and Emission Standards

Fuel System

Injection. Electronic Sequential Port Fuel Injection (ESPFI)

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Consumption

5.00 litres/100 km (20.0 km/l or 47.04 mpg)

Fuel Capacity

13.20 litres / 3.49 US gallons

Greenhouse Gases

116.0 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

Telescopic fork

Rear Suspension

Twin shocks

Tires and Rims

Front Tire

100/90-B19

Rims

Gloss Black, Steel Laced.

Brakes

Front Brakes

Single disc. Optional ABS. 4-piston fixed.

Rear Brakes

Single disc. Optional ABS. 2-piston

Instrumentation and Lighting

Instruments

2.14 inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication

Lighting

High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), 6-speed, low fuel warnings

Notes, Comments and Warranty Information

Colour Options

Vivid Black, Deadwood Green, Stone Washed White Pearl, Baja Orange
