Harley-Davidson Street 750 2020 specifications pictures and more for the 2020 Harley-Davidson Street 750 in South Africa brought to you by Motomedia

Harley-Davidson Street 750 2020 motorcycle info

Main Detail

Make

Harley-Davidson

Model

Street 750

Year

2020

Performance and Speed

Power to Weight Ratio

0.2601 HP/kg

Torque

60.3 Nm (6.2 kgf-m or 44.5 ft.lbs) @ 4000 Revolutions">RPM

Dimensions and Weight

Dry Weight

223.0 kg / 491.6 pounds

Ground Clearance

145 mm / 5.7 inches

Overall Length

2215 mm / 87.2 inches

Trail

115 mm / 4.5 inches

Kerb Weight

233.2 kg / 514.0 pounds

Wheelbase

1534 mm / 60.4 inches

Engine and Exhaust

Bore / Stroke

85.0 x 66.0 mm / 3.3 x 2.6 inches

Engine Capacity

749.0 cc / 45.70 cubic inches

Compression

11.0:1

Engine Detail

Blacked-out Revolution X™ engine

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Black two- into-one

Transmission (Gearbox) and Final Drive

Transmission Type

Belt (final drive)

Gearbox

6-speed

Clutch

Multi-plate with diaphragm spring in oil bath

Drive line

Gear, 36/68 ratio primary drive

Oil Capacity

3.10 litres / 3.28 US quarts

Fuel and Emission Standards

Fuel System

Injection. Mikuni Single Port Fuel Injection, 38 mm bore.

Fuel Control

Single Overhead Cams (SOHC)

Fuel Consumption

4.28 litres/100 km (23.4 km/l or 54.96 mpg)

Fuel Capacity

13.10 litres / 3.46 US gallons

Greenhouse Gases

99.3 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

Telescopic fork

Rear Suspension

Twin shocks

Tires and Rims

Front Tire

100/80-R17

Rims

Black, 7-Spoke Cast Aluminum with Machined Rim Highlights

Brakes

Front Brakes

Single disc. 2-piston floated, optional ABS

Rear Brakes

Single disc. 2-piston floated, optional ABS

Instrumentation and Lighting

Instruments

3.5 inch electronic speedometer with high beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, blade key ignition and fork lock, and locking gas cap

Lighting

High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning

Notes, Comments and Warranty Information

Colour Options

Vivid Black, Performance Orange, Black Denim, Barracuda Silver Deluxe, Vivid Black Deluxe

Harley-Davidson Street 750 2020 specs
