Harley-Davidson Sportster Forty-Eight 2013 motorcycle info

Main Detail

Make

Harley-Davidson

Model

Sportster Forty-Eight

Year

2013

Performance and Speed

Top Speed

45.0 km/h / 28.0 mph

Torque

107.12 Nm (10.9 kgf-m or 79.0 ft.lbs) @ 4000

Dimensions and Weight

Dry Weight

250.8 kg / 553.0 pounds

Ground Clearance

99 mm / 3.9 inches

Overall Height

1,400 mm / 55.1 inches

Overall Length

2,250 mm / 88.6 inches

Overall Width

1,600 mm / 63.0 inches

Trail

107 mm / 4.2 inches

Kerb Weight

259.9 kg / 573.0 pounds

Wheelbase

1,519 mm / 59.8 inches

Engine and Exhaust

Bore / Stroke

88.9 x 96.8 mm / 3.5 x 3.8 inches

Engine Capacity

1201.25 cc / 73.30 cubic inches

Compression

9.7:1

Engine Detail

Air-cooled, Evolution®

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

E Type 9

Transmission (Gearbox) and Final Drive

Transmission Type

Belt

Gearbox

6-speed

Clutch

Multi-plate with diaphragm spring in oil bath

Drive line

57/38 ratio

Lubrication System

Dry sump

Oil Capacity

2.60 litres / 0.17 quarts

Fuel and Emission Standards

Fuel System

Injection. Electronic Sequential Port Fuel Injection (ESPFI)

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Consumption

4.90 litres/100 km (20.4 km/l or 48.00 mpg)

Fuel Capacity

7.95 litres / 2.10 gallons

Greenhouse Gases

113.7 CO

Suspension

Front Suspension

Independent coil springs and hydraulic dampers

Rear Suspension

Independent coil springs and hydraulic dampers

Tires and Rims

Front Tire Dimensions

150/80-16

Rear Tire Dimensions

150/80-B16

Rims

Black, Laced Steel

Brakes

Front Brakes

Single disc. Dual-piston

Rear Brakes

Single disc. Single-piston

Instrumentation and Lighting

Instruments

4-inch Speedometer mounted low and integrated into handlebar clamp electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, LED indicator lights

Lighting

High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional)
