Harley-Davidson Softail Fat Boy 2013 motorcycle info

Main Detail

Make

Harley-Davidson

Model

Softail Fat Boy

Year

2013

Performance and Speed

Top Speed

45.0 km/h / 28.0 mph

Torque

133.84 Nm (13.6 kgf-m or 98.7 ft.lbs) @ 3000

Dimensions and Weight

Dry Weight

313.0 kg / 690.0 pounds

Ground Clearance

130 mm / 5.1 inches

Overall Height

1,400 mm / 55.1 inches

Overall Length

2,395 mm / 94.3 inches

Overall Width

1,600 mm / 63.0 inches

Trail

147 mm / 5.8 inches

Kerb Weight

330.2 kg / 728.0 pounds

Wheelbase

1,638 mm / 64.5 inches

Engine and Exhaust

Bore / Stroke

98.4 x 111.3 mm / 3.9 x 4.4 inches

Engine Capacity

1687.97 cc / 103.00 cubic inches

Compression

9.6:1

Engine Detail

Air-cooled, Twin Cam 103B?

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Chrome, over/under shotgun exhaust with dual mufflers

Transmission (Gearbox) and Final Drive

Transmission Type

Belt

Gearbox

6-speed

Clutch

Multi-plate with diaphragm spring in oil bath

Drive line

Primary chain, 34/46 ratio

Oil Capacity

3.30 litres / 0.22 quarts

Fuel and Emission Standards

Fuel System

Injection. Electronic Sequential Port Fuel Injection (ESPFI)

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Consumption

5.60 litres/100 km (17.9 km/l or 42.00 mpg)

Fuel Capacity

18.93 litres / 5.00 gallons

Greenhouse Gases

129.9 CO

Suspension

Front Suspension

Independent coil springs and hydraulic dampers

Rear Suspension

Independent coil springs and hydraulic dampers

Tires and Rims

Front Tire Dimensions

140/75-R17

Rear Tire Dimensions

200/55-R17

Rims

Silver, Bullet Hole Disc Cast Aluminum

Brakes

Front Brakes

Double disc. 4-piston

Rear Brakes

Single disc. 2-piston

Instrumentation and Lighting

Instruments

Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicat

Lighting

High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), 6-speed, low fuel warnings
