Harley-Davidson Softail Breakout 2016 motorcycle info

Main Detail

Make

Harley-Davidson

Model

Softail Breakout

Year

2016

Performance and Speed

Power to Weight Ratio

0.2430 HP/kg

Torque

130.00 Nm (13.3 kgf-m or 95.9 ft.lbs) @ 3000 Revolutions">RPM

Dimensions and Weight

Dry Weight

309.0 kg / 681.2 pounds

Ground Clearance

120 mm / 4.7 inches

Overall Length

2,445 mm / 96.3 inches

Trail

146 mm / 5.7 inches

Kerb Weight

322.0 kg / 709.9 pounds

Wheelbase

1,710 mm / 67.3 inches

Engine and Exhaust

Bore / Stroke

98.4 x 111.1 mm / 3.9 x 4.4 inches

Compression

9.6:1

Engine Type

V2, four-stroke

Starter

Electric

Exhaust system

Staggered, straight cut chrome mufflers with Gloss Black muffler shields

Transmission (Gearbox) and Final Drive

Transmission Type

Belt

Gearbox

6-speed

Clutch

Multi-plate with diaphragm spring in oil bath

Drive line

Chain, 34/46 ratio primary drive

Oil Capacity

3.30 litres / 0.22 quarts

Fuel and Emission Standards

Fuel System

Injection. Electronic Sequential Port Fuel Injection

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Consumption

5.60 litres/100 km (17.9 km/l or 42.00 mpg)

Fuel Capacity

18.93 litres / 5.00 gallons

Greenhouse Gases

129.9 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

Telescopic fork

Rear Suspension

Twin shocks

Tires and Rims

Front Tire

130/60-B21

Rear Tire

240/40-R18

Rims

Black, 10-Spoke Cast Aluminum

Brakes

Front Brakes

Single disc. ABS. 4-piston

Rear Brakes

Single disc. ABS. 2-piston

Instrumentation and Lighting

Lighting

High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), 6-speed, low fuel warnings

Notes, Comments and Warranty Information

Colour Options

Velocity Red Candy, Hard Candy Black Gold Flake, Billet Silver, Charcoal Denim, Vivid Black, Crushed Ice Pearl , Morocco Gold Pearl, Amber Whiskey, Vivid Black
