Harley-Davidson Road King 2022 specifications pictures and more for the 2022 Harley-Davidson Road King in South Africa brought to you by Motomedia

Harley-Davidson Road King 2022 motorcycle info

Main Detail

Make

Harley-Davidson

Model

Road King

Year

2022

Performance and Speed

Power to Weight Ratio

0.2471 HP/kg

Torque

150.5 Nm (15.3 kgf-m or 111.0 ft.lbs) @ 3250 Revolutions">RPM

Dimensions and Weight

Dry Weight

360.2 kg / 794.0 pounds

Ground Clearance

135 mm / 5.3 inches

Overall Length

2450 mm / 96.5 inches

Trail

170 mm / 6.7 inches

Kerb Weight

375.6 kg / 828.0 pounds

Wheelbase

1625 mm / 64.0 inches

Engine and Exhaust

Bore / Stroke

100.0 x 111.1 mm / 3.9 x 4.4 inches

Engine Capacity

1746.0 cc / 106.54 cubic inches

Compression

10.0:1

Engine Detail

Milwaukee-Eight® 107, Integrated Oil-Cooler

Engine Type

V2, four-stroke

Starter

Electric

Exhaust system

Chrome, 2-1-2 dual exhaust with tapered mufflers

Transmission (Gearbox) and Final Drive

Transmission Type

Belt (final drive)

Gearbox

6-speed

Clutch

Multi-plate with diaphragm spring in oil bath

Drive line

Chain, 34/46 ratio primary drive

Lubrication System

Dry sump

Oil Capacity

4.90 litres / 5.18 US quarts

Fuel and Emission Standards

Fuel System

Injection. Electronic Sequential Port Fuel Injection

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Consumption

5.47 litres/100 km (18.3 km/l or 43.00 mpg)

Fuel Capacity

22.71 litres / 6.00 US gallons

Greenhouse Gases

126.9 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

Telescopic fork, 49 mm dual bending valve

Fork Tube Size

49 mm / 1.9 inches

Rear Suspension

Twin shocks. Premium standard height hand-adjustable.

Carrying Capacity

Saddle bags, 2.3 cu ft volume

Tires and Rims

Front Tire

130/70-B18

Rims

Slicer II Cast Aluminum wheels. Dunlop® Harley-Davidson Series, bias blackwall tires.

Brakes

Front Brakes

Double disc. Optional ABS. 4-piston

Rear Brakes

Single disc. Optional ABS. 4-piston

Instrumentation and Lighting

Instruments

Display features odometer, trip A, trip B, range to empty and gear indicator; and larger tell-tale indicators.

Lighting

High beam, running lights, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, battery, security system, low fuel warning, cruise control, ABS, Gear/RPM display, miles to empty display
