Harley-Davidson Pan America 1250 2021 specifications pictures and more for the 2021 Harley-Davidson Pan America 1250 in South Africa brought to you by Motomedia

Harley-Davidson Pan America 1250 2021 motorcycle info

Main Detail

Make

Harley-Davidson

Model

Pan America 1250

Year

2021

Performance and Speed

Power to Weight Ratio

0.6275 HP/kg

Torque

127.5 Nm (13.0 kgf-m or 94.0 ft.lbs) @ 6750 Revolutions">RPM

Dimensions and Weight

Dry Weight

239.0 kg / 527.0 pounds

Ground Clearance

211 mm / 8.3 inches

Overall Length

2266 mm / 89.2 inches

Trail

157 mm / 6.2 inches

Kerb Weight

253.6 kg / 559.0 pounds

Wheelbase

1580 mm / 62.2 inches

Engine and Exhaust

Bore / Stroke

104.9 x 72.4 mm / 4.1 x 2.9 inches

Engine Capacity

1250.4 cc / 76.30 cubic inches

Compression

13.0:1

Engine Detail

Revolution® Max 1250 engine

Engine Type

V2, four-stroke

Starter

Electric

Exhaust system

2-into-1-into-1; catalyst in header

Transmission (Gearbox) and Final Drive

Transmission Type

Chain (final drive)

Gearbox

6-speed

Lubrication System

Dry sump

Oil Capacity

4.50 litres / 4.76 US quarts

Fuel and Emission Standards

Fuel System

Injection. Electronic Sequential Port Fuel Injection

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Consumption

5.11 litres/100 km (19.6 km/l or 46.03 mpg)

Fuel Capacity

21.20 litres / 5.60 US gallons

Greenhouse Gases

118.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

47mm inverted fork with electronically adjustable semi-active damping control. Aluminum fork triple clamps.

Front Wheel Travel

190 mm / 7.5 inches

Rear Suspension

Linkage-mounted monoshock with automatic electronic preload control and semi-active compression and rebound damping

Tires and Rims

Front Tire

120/70-R19

Rims

Aluminum cast, black

Brakes

Front Brakes

Double disc. Radially mounted, monoblock, 4-piston caliper. Optional ABS.

Rear Brakes

Single disc. Floating, single piston caliper. Optional ABS.

Instrumentation and Lighting

Instruments

6.8 inch TFT color display with speedometer, gear, odometer, fuel level, clock, trip, ambient temp, low temp alert, side stand down alert, TIP over alert, cruise, range and tachometer

Lighting

Daymaker® Signature Adaptive Headlamp

Notes, Comments and Warranty Information

Comments

Available from May 2021. Windscreen, cruise control, six-axis IMU, customizable ride modes, Bluetooth connectivity and moving map navigation.

Colour Options

Vivid Black, Gauntlet Grey Metallic, Baja Orange/Stone Washed White Pearl
