Ducati XDiavel 2016 specifications pictures and more for the 2016 Ducati XDiavel in South Africa brought to you by Motomedia

Ducati XDiavel 2016 motorcycle info

Main Detail

Make

Ducati

Model

XDiavel

Year

2016

Performance and Speed

Power to Weight Ratio

0.7091 HP/kg

Torque

128.90 Nm (13.1 kgf-m or 95.1 ft.lbs) @ 5000 Revolutions">RPM

Dimensions and Weight

Dry Weight

220.0 kg / 485.0 pounds

Overall Length

2,235 mm / 88.0 inches

Trail

130 mm / 5.1 inches

Kerb Weight

247.0 kg / 544.5 pounds

Wheelbase

1,615 mm / 63.6 inches

Engine and Exhaust

Bore / Stroke

106.0 x 71.5 mm / 4.2 x 2.8 inches

Engine Capacity

1262.00 cc / 77.01 cubic inches

Compression

13.0:1

Engine Detail

Ducati Testastretta DVT (Desmodromic Variable Timing) engine

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Stainless steel exhaust and muffler with dual oval exits

Transmission (Gearbox) and Final Drive

Transmission Type

Belt

Gearbox

6-speed

Clutch

Slipper and self-servo wet multiplate clutch with hydraulic control.

Fuel and Emission Standards

Fuel System

Injection. Bosch fuel injection system. Full ride-by-wire system.

Fuel Control

Desmodromic valve control

Fuel Capacity

17.00 litres / 4.49 gallons

Emission Details

Euro 3

Suspension

Front Suspension

Adjustable usd forks

Front Wheel Travel

120 mm / 4.7 inches

Rear Suspension

Single shock absorber, Adjustable preload and rebound

Rear Wheel Travel

110 mm / 4.3 inches

Tires and Rims

Front Tire

120/70-ZR17

Rear Tire

240/45-ZR17

Rims

14-spoke in light alloy

Brakes

Front Brakes

Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted.

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc. ABS. Floating disc. Two-piston calipers.

Rear Brake Diameter

265 mm / 10.4 inches

Notes, Comments and Warranty Information

Factory Warranty

24 months unlimited mileage

Colour Options

Dark Stealth

Ducati XDiavel 2016 specs
