Ducati Panigale V4 2020 specifications pictures and more for the 2020 Ducati Panigale V4 in South Africa brought to you by Motomedia

Ducati Panigale V4 2020 motorcycle info

Main Detail

Make

Ducati

Model

Panigale V4

Year

2020

Performance and Speed

Power to Weight Ratio

1.2229 HP/kg

Torque

124.0 Nm (12.6 kgf-m or 91.5 ft.lbs) @ 10000 Revolutions">RPM

Dimensions and Weight

Dry Weight

175.0 kg / 385.8 pounds

Overall Height

845 mm / 33.3 inches

Trail

100 mm / 3.9 inches

Kerb Weight

198.0 kg / 436.5 pounds

Wheelbase

1469 mm / 57.8 inches

Engine and Exhaust

Bore / Stroke

81.0 x 53.5 mm / 3.2 x 2.1 inches

Engine Capacity

1103.0 cc / 67.31 cubic inches

Compression

14.0:1

Engine Detail

L-twin

Engine Type

V4, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

4-2-1-2 system with 2 catalytic converter and 2 lambda probes.

Transmission (Gearbox) and Final Drive

Transmission Type

Chain (final drive)

Gearbox

6-speed

Clutch

Slipper and self-servo wet multiplate clutch with hydraulic control

Fuel and Emission Standards

Fuel System

Injection. Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies.

Fuel Control

Desmodromic valve control

Fuel Consumption

6.90 litres/100 km (14.5 km/l or 34.09 mpg)

Fuel Capacity

16.00 litres / 4.23 US gallons

Emission Details

Euro 4

Greenhouse Gases

160.1 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

Showa BPF 43mm fork

Front Wheel Travel

120 mm / 4.7 inches

Rear Suspension

Fully adjustable Sachs unit. Aluminium single-sided swingarm.

Rear Wheel Travel

130 mm / 5.1 inches

Tires and Rims

Front Tire

120/70-ZR17

Rims

Cast aluminium 5-spoke

Brakes

Front Brakes

Double disc. ABS. Brembo

Rear Brakes

Single disc. ABS. Brembo

Instrumentation and Lighting

Instruments

Digital unit with TFT colour display rev counter, speed, gear selected, odometer, etc.

Lighting

LED headlight

Notes, Comments and Warranty Information

Comments

Power and torque can be raised to 220 hp (162 kW) and 130 Nm (13.2 kgm) by fitting the full-racing Ducati Performance exhaust by Akrapovi and #269; that also reduces weight by – 6 kg.

Factory Warranty

24 months unlimited mileage

Colour Options

Ducati Red
