Ducati Multistrada 1200 S Granturismo 2014 specifications pictures and more for the 2014 Ducati Multistrada 1200 S Granturismo in South Africa brought to you by Motomedia

Ducati Multistrada 1200 S Granturismo 2014 motorcycle info

Main Detail

Make

Ducati

Model

Multistrada 1200 S Granturismo

Year

2014

Performance and Speed

Power to Weight Ratio

0.6912 HP/kg

Torque

124.50 Nm (12.7 kgf-m or 91.8 ft.lbs) @ 7500

Dimensions and Weight

Dry Weight

217.0 kg / 478.4 pounds

Overall Height

1,408 mm / 55.4 inches

Overall Length

2,195 mm / 86.4 inches

Overall Width

793 mm / 31.2 inches

Trail

110 mm / 4.3 inches

Kerb Weight

234.0 kg / 515.9 pounds

Wheelbase

1,530 mm / 60.2 inches

Engine and Exhaust

Bore / Stroke

106.0 x 67.9 mm / 4.2 x 2.7 inches

Engine Capacity

1198.40 cc / 73.13 cubic inches

Compression

11.5:1

Engine Detail

L-Twin cylinder

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Stainless steel muffler with catalytic converter and 2 lambda probes, alluminium tail pipes

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run

Lubrication System

Dry sump

Fuel and Emission Standards

Fuel System

Injection. Mitsubishi electronic fuel injection system, Mikuni elliptical throttle bodies

Fuel Control

Desmodromic valve control

Fuel Capacity

20.00 litres / 5.28 gallons

Reserve Fuel Capacity

2.50 litres / 0.66 gallons

Emission Details

Euro III

Suspension

Front Suspension

Sachs 48mm fully adjustable usd forks. Electronic compression and rebound damping adjustment with Ducati Skyhook Suspension

Front Wheel Travel

150 mm / 5.9 inches

Rear Suspension

Electronic compression and rebound damping adjustment. Electronic spring pre-load adjustment with DSS Aluminium single-sided swingarm.

Rear Wheel Travel

150 mm / 5.9 inches

Carrying Capacity

Top box, saddle bags

Tires and Rims

Front Tire

90/90-21

Front Tire Dimensions

120/70-17

Rear Tire

130/90-17

Rear Tire Dimensions

190/55-17

Brakes

Front Brakes

Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted.

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc. Two-piston calipers.

Rear Brake Diameter

245 mm / 9.6 inches

Instrumentation and Lighting

Instruments

Multifunction digital dashboard.

Notes, Comments and Warranty Information

Comments

Windscreen

Factory Warranty

2 years unlimited mileage

Colour Options

Grey, red

Ducati Multistrada 1200 S Granturismo 2014 specs
