Ducati Multistrada 1200 2012 specifications pictures and more for the 2012 Ducati Multistrada 1200 in South Africa brought to you by Motomedia

Ducati Multistrada 1200 2012 motorcycle info

Main Detail

Make

Ducati

Model

Multistrada 1200

Year

2012

Performance and Speed

Power to Weight Ratio

0.7937 HP/kg

Torque

118.65 Nm (12.1 kgf-m or 87.5 ft.lbs) @ 7500

Dimensions and Weight

Dry Weight

189.0 kg / 416.7 pounds

Kerb Weight

220.0 kg / 485.0 pounds

Wheelbase

1,530 mm / 60.2 inches

Engine and Exhaust

Bore / Stroke

106.0 x 67.9 mm / 4.2 x 2.7 inches

Engine Capacity

1198.40 cc / 73.13 cubic inches

Compression

11.5:1

Engine Detail

Type L-Twin cylinder

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Stainless steel muffler with catalytic converter and 2 lambda probes, aluminium tail pipes

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Light action, wet, multiplate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run

Drive line

Primary drive Straight cut gears, Ratio 1.84:1: Chain 5.30; Front sprocket 15; Rear sprocket 40

Fuel and Emission Standards

Fuel System

Injection. Tsubishi electronic fuel injection system, Mikuni elliptical throttle bodies

Fuel Control

Desmodromic valve control

Fuel Capacity

20.00 litres / 5.28 gallons

Emission Details

Follows the US Federal Regulation. Euro 3.

Suspension

Front Suspension

Marzocchi 50mm fully adjustable usd forks

Front Suspension Travel

170 mm / 6.7 inches

Front Wheel Travel

130 mm / 5.1 inches

Rear Suspension

Progressive linkage with fully adjustable Sachs monoshock. Aluminium single-sided swingarm

Rear Wheel Travel

148 mm / 5.8 inches

Tires and Rims

Front Tire

120/70-ZR17

Front Tire Dimensions

120/70-17

Rear Tire

180/55-ZR17

Rear Tire Dimensions

190/55-17

Rims

10-spoke in light alloy

Brakes

Front Brakes

Double disc. Optional ABS

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc. Optional ABS

Rear Brake Diameter

245 mm / 9.6 inches

Instrumentation and Lighting

Instruments

Digital unit displaying: Speedometer, rev counter, time, scheduled maintenance warning, oil temperature, trip fuel, lap time, warning light for low oil pressure, fuel level, fuel reserve, neutral, turn signals, warning ABS, overrev, DTC, immobilizer. Read

Notes, Comments and Warranty Information

Factory Warranty

2 years unlimited mileage

Colour Options

Red, white

Ducati Multistrada 1200 2012 specs
