Ducati Monster 821 2016 specifications pictures and more for the 2016 Ducati Monster 821 in South Africa brought to you by Motomedia

Ducati Monster 821 2016 motorcycle info

Main Detail

Make

Ducati

Model

Monster 821

Year

2016

Performance and Speed

Power to Weight Ratio

0.6240 HP/kg

Torque

89.40 Nm (9.1 kgf-m or 65.9 ft.lbs) @ 7750 Revolutions">RPM

Dimensions and Weight

Dry Weight

179.5 kg / 395.7 pounds

Overall Height

1,055 mm / 41.5 inches

Overall Length

2,170 mm / 85.4 inches

Overall Width

800 mm / 31.5 inches

Trail

93 mm / 3.7 inches

Kerb Weight

205.5 kg / 453.0 pounds

Wheelbase

1,480 mm / 58.3 inches

Engine and Exhaust

Bore / Stroke

88.0 x 67.5 mm / 3.5 x 2.7 inches

Engine Capacity

821.00 cc / 50.10 cubic inches

Compression

12.8:1

Engine Detail

Testastretta 11° L-Twin

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Stainless steel muffler and aluminium and cap; lightweight 2-1 system with catalytic converter with 2 lambda probes

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

APTC slipper and self-servo wet multiplate clutch with control cable

Fuel and Emission Standards

Fuel System

Injection. 53mm throttle bodies with full Ride by Wire

Fuel Control

Desmodromic valve control

Fuel Capacity

17.50 litres / 4.62 gallons

Emission Details

Euro 3

Suspension

Front Suspension

43mm upside-down forks

Front Wheel Travel

130 mm / 5.1 inches

Rear Suspension

Progressive linkage with adjustable monoshock. Aluminium double-sided swingarm

Rear Wheel Travel

140 mm / 5.5 inches

Tires and Rims

Front Tire

120/70-ZR17

Rear Tire

180/55-ZR17

Rims

10-spoke in light alloy

Brakes

Front Brakes

Double disc. Semi-floating discs, radially mounted Monobloc Brembo M4-32 callipers, 4-pistons, axiial pump with ABS as standard

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc. 2-piston floating calliper with ABS as standard equipment

Rear Brake Diameter

245 mm / 9.6 inches

Instrumentation and Lighting

Instruments

LCD display

Notes, Comments and Warranty Information

Comments

Three Riding Modes.

Factory Warranty

24 months unlimited mileage

Colour Options

Star White Silk, Red

Ducati Monster 821 2016 specs
