Ducati Monster 796 2011 specifications pictures and more for the 2011 Ducati Monster 796 in South Africa brought to you by Motomedia

Ducati Monster 796 2011 motorcycle info

Main Detail

Make

Ducati

Model

Monster 796

Year

2011

Performance and Speed

Power to Weight Ratio

0.5140 HP/kg

Top Speed

105.0 km/h / 65.2 mph

Torque

58.00 Nm (5.9 kgf-m or 42.8 ft.lbs)

Dimensions and Weight

Dry Weight

167.0 kg / 368.2 pounds

Ground Clearance

295 mm / 11.6 inches

Overall Height

1,150 mm / 45.3 inches

Overall Length

1,830 mm / 72.0 inches

Overall Width

1,090 mm / 42.9 inches

Wheelbase

1,450 mm / 57.1 inches

Engine and Exhaust

Bore / Stroke

88.0 x 66.0 mm / 3.5 x 2.6 inches

Engine Capacity

803.00 cc / 49.00 cubic inches

Compression

11.0:1

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Lightweight 2-1-2 system with catalytic converter with twin lambda probes

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

APTC wet multiplate with hydraulic control

Drive line

Chain; Front sprocket 15; Rear sprocket 39

Lubrication System

Forced Pressure and Wet Sump

Oil Capacity

2.50 litres / 0.17 quarts

Fuel and Emission Standards

Fuel System

Injection. Siemens electronic fuel injection, 45mm throttle body

Fuel Control

Desmodromic valve control

Fuel Capacity

15.00 litres / 3.96 gallons

Suspension

Front Suspension

Marzocchi 43mm upside-down forks

Front Suspension Travel

120 mm / 4.7 inches

Front Wheel Travel

279 mm / 11.0 inches

Rear Suspension

Progressive linkage with preload and rebound Sachs adjustable monoshock

Rear Wheel Travel

254 mm / 10.0 inches

Tires and Rims

Front Tire

21/7-10

Front Tire Dimensions

120/70-ZR17

Rear Tire

20/10-12

Rear Tire Dimensions

180/55-ZR17

Brakes

Front Brakes

Double disc. Optional Anti-Lock braking

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc

Rear Brake Diameter

245 mm / 9.6 inches

Notes, Comments and Warranty Information

Factory Warranty

2 years unlimited mileage

Colour Options

Red (red/back), Arctic white silk (red/back), Diamond black silk (red/back), Monster Art colours (red/back)

Ducati Monster 796 2011 specs
