Ducati Monster 1200 R 2016 specifications pictures and more for the 2016 Ducati Monster 1200 R in South Africa brought to you by Motomedia

Ducati Monster 1200 R 2016 motorcycle info

Main Detail

Make

Ducati

Model

Monster 1200 R

Year

2016

Performance and Speed

Power to Weight Ratio

0.8889 HP/kg

Torque

134.00 Nm (13.7 kgf-m or 98.8 ft.lbs) @ 7750 Revolutions">RPM

Dimensions and Weight

Dry Weight

180.0 kg / 396.8 pounds

Overall Height

1,050 mm / 41.3 inches

Overall Length

2,121 mm / 83.5 inches

Overall Width

830 mm / 32.7 inches

Trail

89 mm / 3.5 inches

Kerb Weight

207.0 kg / 456.4 pounds

Wheelbase

1,508 mm / 59.4 inches

Engine and Exhaust

Bore / Stroke

106.0 x 67.9 mm / 4.2 x 2.7 inches

Engine Capacity

1198.40 cc / 73.13 cubic inches

Compression

13.0:1

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

2-1-2 staggered shotgun exhaust

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Wet, multi-plate clutch with hydraulic control. Self-servo action on drive, slipper action on over-run

Fuel and Emission Standards

Fuel System

Injection. Synerject-Continental electronic fuel injection system, elliptical throttle body ? 56 mm equivalent with full Ride-by-Wire

Fuel Control

Desmodromic valve control

Fuel Capacity

17.50 litres / 4.62 gallons

Emission Details

Euro 4

Suspension

Front Suspension

?hlins usd forks

Front Wheel Travel

130 mm / 5.1 inches

Rear Suspension

?hlins mono-shock with integrated piggy-back, fully adjustable in spring preload with full adjustment

Rear Wheel Travel

159 mm / 6.3 inches

Tires and Rims

Front Tire

120/70-ZR17

Rear Tire

190/55-ZR17

Rims

Tri-W spoke forged alloy

Brakes

Front Brakes

Double disc. ABS. Bremo. Four-piston calipers. Radially mounted.

Front Brake Diameter

330 mm / 13.0 inches

Rear Brakes

Single disc. ABS. Bremo. Floating disc. Two-piston calipers.

Rear Brake Diameter

245 mm / 9.6 inches

Instrumentation and Lighting

Instruments

Colour TFT display

Notes, Comments and Warranty Information

Factory Warranty

2 years unlimited mileage

Colour Options

Red, Star White
