Ducati Diavel 2016 specifications pictures and more for the 2016 Ducati Diavel in South Africa brought to you by Motomedia

Ducati Diavel 2016 motorcycle info

Main Detail

Make

Ducati

Model

Diavel

Year

2016

Performance and Speed

Power to Weight Ratio

0.7714 HP/kg

Torque

130.00 Nm (13.3 kgf-m or 95.9 ft.lbs) @ 8000 Revolutions">RPM

Dimensions and Weight

Dry Weight

210.0 kg / 463.0 pounds

Overall Length

2,235 mm / 88.0 inches

Trail

130 mm / 5.1 inches

Kerb Weight

239.0 kg / 526.9 pounds

Wheelbase

1,590 mm / 62.6 inches

Engine and Exhaust

Bore / Stroke

106.0 x 67.9 mm / 4.2 x 2.7 inches

Engine Capacity

1198.40 cc / 73.13 cubic inches

Compression

12.5:1

Engine Detail

Testastretta 11° L-Twin engine

Engine Type

V2, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Stainless steel muffler with aluminium tips

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Slipper and self-servo wet multiplate clutch with hydraulic control.

Drive line

Front sprocket 15; Rear sprocket 43. Primary drive: Straight cut gears, ratio 1.84.

Fuel and Emission Standards

Fuel System

Injection. Elliptical throttle bodies, fully ride-by-wire controlled

Fuel Control

Desmodromic valve control

Fuel Capacity

17.00 litres / 4.49 gallons

Emission Details

Euro 3

Suspension

Front Suspension

Marzocchi 50mm fully adjustable usd forks

Front Wheel Travel

120 mm / 4.7 inches

Rear Suspension

Progressive linkage with fully adjustable Sachs monoshock. Remote spring preload adjustment. Aluminium single-sided swingarm

Rear Wheel Travel

120 mm / 4.7 inches

Tires and Rims

Front Tire

120/70-ZR17

Rear Tire

240/45-ZR17

Rims

14-spoke in light alloy

Brakes

Front Brakes

Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted.

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc. ABS. Floating disc. Two-piston calipers.

Rear Brake Diameter

265 mm / 10.4 inches

Instrumentation and Lighting

Instruments

Handlebar mounted instrumentation with LCD display speed, rpm, time, coolant temp.

Lighting

LED headlight

Notes, Comments and Warranty Information

Factory Warranty

24 months unlimited mileage

Colour Options

Dark Stealth

Ducati Diavel 2016 specs
