Ducati Diavel 1260 S 2020 specifications pictures and more for the 2020 Ducati Diavel 1260 S in South Africa brought to you by Motomedia

Ducati Diavel 1260 S 2020 motorcycle info

Main Detail

Make

Ducati

Model

Diavel 1260 S

Year

2020

Performance and Speed

Power to Weight Ratio

0.7294 HP/kg

Torque

129.0 Nm (13.2 kgf-m or 95.2 ft.lbs) @ 7500 Revolutions">RPM

Dimensions and Weight

Dry Weight

218.0 kg / 480.6 pounds

Overall Length

2200 mm / 86.6 inches

Trail

120 mm / 4.7 inches

Kerb Weight

244.0 kg / 537.9 pounds

Wheelbase

1600 mm / 63.0 inches

Engine and Exhaust

Bore / Stroke

106.0 x 71.5 mm / 4.2 x 2.8 inches

Engine Capacity

1262.0 cc / 77.01 cubic inches

Compression

13.0:1

Engine Detail

Testastretta DVT

Engine Type

V2, four-stroke

Ignition

Dual Spark

Starter

Electric

Valves / Cylinder

Exhaust system

Stainless steel muffler with catalytic converter and 2 lambda probes, alluminium tail pipes

Transmission (Gearbox) and Final Drive

Transmission Type

Chain (final drive)

Gearbox

6-speed

Clutch

Slipper and self-servo wet multiplate clutch with hydraulic control

Drive line

Chain

Fuel and Emission Standards

Fuel System

Injection. Bosch electronic fuel injection system, elliptical throttle bodies with Ride-by-Wire, equivalent diameter 56 mm

Fuel Control

Desmodromic valve control

Fuel Consumption

5.40 litres/100 km (18.5 km/l or 43.56 mpg)

Fuel Capacity

17.00 litres / 4.49 US gallons

Emission Details

Euro 4

Greenhouse Gases

125.3 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

Ø 48 mm Öhlins adjustable usd fork, TiN treatment.

Front Wheel Travel

120 mm / 4.7 inches

Rear Suspension

Öhlins fully adjustable monoshock, Aluminium casted single-sided swingarm.

Rear Wheel Travel

130 mm / 5.1 inches

Tires and Rims

Front Tire

120/70-17

Rims

Light alloy casted and machined

Brakes

Front Brakes

Double disc. ABS. Floating discs. Four-piston calipers. Radially mounted.

Rear Brakes

Single disc. ABS. Two-piston calipers.

Instrumentation and Lighting

Instruments

TFT colour display and dedicated warning light display

Notes, Comments and Warranty Information

Comments

Bosch Cornering ABS Evo, Ducati Traction Control Evo DTC. Riding Modes, Power Modes, Ducati Wheelie Control Evo (DWC).

Factory Warranty

2 years unlimited mileage

Colour Options

Ducati Red, Total Black
