BMW K 1300 S 2011 specifications pictures and more for the 2011 BMW K 1300 S in South Africa brought to you by Motomedia

BMW K 1300 S 2011 motorcycle info

Main Detail

Make

BMW

Model

K 1300 S

Year

2011

Performance and Speed

Power to Weight Ratio

0.7587 HP/kg

Torque

140.00 Nm (14.3 kgf-m or 103.3 ft.lbs) @ 8250

Dimensions and Weight

Dry Weight

228.0 kg / 502.7 pounds

Ground Clearance

1,278 mm / 50.3 inches

Overall Height

1,221 mm / 48.1 inches

Overall Length

2,182 mm / 85.9 inches

Overall Width

905 mm / 35.6 inches

Trail

104 mm / 4.1 inches

Kerb Weight

254.0 kg / 560.0 pounds

Wheelbase

1,585 mm / 62.4 inches

Engine and Exhaust

Bore / Stroke

80.0 x 64.3 mm / 3.1 x 2.5 inches

Engine Capacity

1293.00 cc / 78.90 cubic inches

Compression

13.0:1

Engine Type

In-line four, four-stroke

Starter

Electric

Valves / Cylinder

Exhaust system

Closed-loop 3-way catalytic converter, emission standard EU-3

Transmission (Gearbox) and Final Drive

Transmission Type

Shaft drive (cardan)

Gearbox

6-speed

Clutch

Multiple-disc clutch in oil bath, hydraulically operated

Drive line

Automatic CVT with EBS, Hi/Lo Range and Reverse. 2/4 WD + Diff Lock

Lubrication System

Dry sump

Fuel and Emission Standards

Fuel System

Injection. Electronic intake pipe injection/digital engine management including knock sensor (BMS-K)

Fuel Control

DOHC

Fuel Consumption

4.70 litres/100 km (21.3 km/l or 50.05 mpg)

Fuel Capacity

19.00 litres / 5.02 gallons

Reserve Fuel Capacity

4.00 litres / 1.06 gallons

Emission Details

Closed-loop 3-way catalytic converter, emission standard EU-3

Greenhouse Gases

109.0 CO

Suspension

Front Suspension

BMW Motorrad Duolever

Front Suspension Travel

115 mm / 4.5 inches

Front Wheel Travel

254 mm / 10.0 inches

Rear Suspension

Cast aluminium single-sided swing arm with BMW Motorrad Paralever

Rear Wheel Travel

254 mm / 10.0 inches

Carrying Capacity

Front Rack Capacity 100 lbs / 45.4 kg. Rear Rack Capacity 50 lbs / 22.7 kg. Towing Capacity 1,050 lbs / 476.3 kg

Tires and Rims

Front Tire

25/8-12

Front Tire Dimensions

120/70-ZR17

Rear Tire

25/10-12

Rear Tire Dimensions

190/55-ZR17

Rims

Cast aluminium

Brakes

Front Brakes

Double disc. Optional Anti-Lock Brakes

Front Brake Diameter

320 mm / 12.6 inches

Rear Brakes

Single disc

Rear Brake Diameter

265 mm / 10.4 inches

Notes, Comments and Warranty Information

Comments

Power Steering

Colour Options

Light gray, blue/white/black, red/black

BMW K 1300 S 2011 specs
