BMW F 800 GS 2016 specifications pictures and more for the 2016 BMW F 800 GS in South Africa brought to you by Motomedia

BMW F 800 GS 2016 motorcycle info

Main Detail

Make

BMW

Model

F 800 GS

Year

2016

Performance and Speed

Power to Weight Ratio

0.4450 HP/kg

Torque

83.00 Nm (8.5 kgf-m or 61.2 ft.lbs) @ 5750 Revolutions">RPM

Dimensions and Weight

Dry Weight

191.0 kg / 421.1 pounds

Overall Height

1,350 mm / 53.1 inches

Overall Length

2,320 mm / 91.3 inches

Overall Width

945 mm / 37.2 inches

Trail

117 mm / 4.6 inches

Kerb Weight

214.0 kg / 471.8 pounds

Wheelbase

1,578 mm / 62.1 inches

Engine and Exhaust

Bore / Stroke

82.0 x 75.6 mm / 3.2 x 3.0 inches

Compression

12.0:1

Engine Type

Twin, four-stroke

Starter

Electric

Valves / Cylinder

Transmission (Gearbox) and Final Drive

Transmission Type

Chain

Gearbox

6-speed

Clutch

Multiple-disc clutch in oil bath, mechanically operated

Drive line

Endless O-ring chain with shock damping in rear wheel hub

Lubrication System

Dry sump

Fuel and Emission Standards

Fuel System

Injection. Electroinc intake pipe injection, digital engine management (BMS-K+)

Fuel Control

Double Overhead Cams/Twin Cam (DOHC)

Fuel Consumption

3.80 litres/100 km (26.3 km/l or 61.90 mpg)

Fuel Capacity

16.00 litres / 4.23 gallons

Reserve Fuel Capacity

4.00 litres / 1.06 gallons

Emission Details

Closed-loop 3-way catalytic converter, emission standard EU-3

Greenhouse Gases

88.2 CO2 g/km. (CO2 - Carbon dioxide emission)

Suspension

Front Suspension

Upside-down telescopic fork, 43 mm

Front Wheel Travel

230 mm / 9.1 inches

Rear Suspension

Cast aluminium dual swing arm, WAD strut (travel related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable

Rear Wheel Travel

215 mm / 8.5 inches

Tires and Rims

Front Tire

90/90-21

Rear Tire

150/70-17

Rims

Wire spoke wheels

Brakes

Front Brakes

Double disc. ABS. Floating discs. Two-piston calipers.

Front Brake Diameter

300 mm / 11.8 inches

Rear Brakes

Single disc. ABS. Floating disc. Single-piston caliper.

Rear Brake Diameter

265 mm / 10.4 inches

Notes, Comments and Warranty Information

Comments

Switchable ABS.

Colour Options

Blackstorm Metallic, Racing Blue Metallic Matte, Light White
